IPPC1660-A11 features a 15.6-inch display diagonal with a maximum brightness of 400 nits. The maximum resolution is 1366x768 (HD). The touch screen is made using PCAP technology, which provides it with high response speed and accuracy. Dimensions are396.99x257.11x65.7 mm.
IPPC2160-A11 also comes with a PCAP touch screen, but with a resolution of 1920x1080 (FHD). The display diagonal is 21.5” with a maximum brightness of 250 nits. Dimensions are 549.19x345.79x66.5 mm.
IPPC2460-A11 has a screen diagonal of 23.8 inches, a resolution of 1920x1080 (FHD) maximum brightness of 450 nits. The screen is also equipped with PCAP technology. Dimensions are 590x366.6x71.66 mm.
These panel computers are based on integrated Intel N97 CPU, providing high performance and low power consumption.
The mainboard has one SO-DIMM DDR5 RAM slot. The pre-installed memory capacity is 8 GB, the maximum you can install is 16 GB.
The chassis is black and made of aluminum alloy and steel. The front panel is fully protected from dust and moisture according to the international standard IP66.
Technical specifications of the new IPPC XX60-A11:
- Two COM ports (Type DB9)
- Two USB 3.2 ports (Type-A)
- Two Lan ports Ethernet Intel I210AT
- One Display port supporting up to 4K 60 Hz
- One USB 3.2 Type-C
- One Mini PCIe slot supports Wi-Fi/FBI/LTE
- One M.2 Key B SSD port for storage
- One M.2 Key B port for 5G/LTE
- One slot for nano-SIM
- Internal USB 2.0 (Type-A)
- One PCIe slot
- Input voltage 24V DC
- Operating temperature from -10°C to +55°C
Nexcom continues to expand their range of industrial panel computers. Thus, the new products have a more protected chassis and improved technical characteristics.
