XP-9781-IoT

XP-9781-IoT Microsoft Windows IoT 10 Controller with Intel Atom E3845, 64GB SSD, 32GB CF Card, Dual GbE LAN The XP-9781-IoT is a multifunctional industrial controller built on a combination of Microsoft Windows 10 IoT and numerous expansion slots to deliver an optimal solution for artificial intelligence applications and SBS/PAC implementations in computing data. The processor of the PC-compatible Microsoft Windows 10 IoT controller is an Intel Atom E3845 Quad Core CPU with a clock frequency of 1.91GHz, which acts as a central instance to coordinate the individual modules. For these, the SBC/PAC controller provides seven expansion slots that enable individual configuration of the hardware. Storage media include an onboard 4GB DDR3 RAM and a CF socket with a pre-installed SSD of 32GB and a 64GB mSATA flash memory for the operating system. Interfaces include electrically isolated Serial COM ports for RS232 and RS485 as well as quad USB 2.0, dual GbE LAN and HDMI plus VGA for graphical output with up to 2560 x 1600 pixels on a maximum of two independent displays. The SBS/PAC controller's expansion via I-9K or I-97K modules allows the system to be optimally adapted to individual requirements, creating a scalable basis for integration into different IT systems, with Microsoft Windows IoT 10 serving as the interface between the local instance and a homogeneous or heterogeneous IT infrastructure.
