W55L100-MRA1FP
Winmate
SKU: 57905700
55" Marine 4K Panel Display, IEC60945/DNVGL/IACS E10, IP66 Front, 3840x2160, 500cd/m2, PCAP Touch, VGA, DVI-D, 2xHDMI, DP, 1xUSB, 1xCOM, 9-36VDC-in w/ PSU, -15..55C
Price on request
Available
Available
Construction
Construction Chassis
Aluminium Chassis
Mounting Configuration
Panel, VESA 200, VESA 200x100
Protection Level of Front Side (Panel)
IP66
Material Front Side (Panel)
Aluminum
Display
Display Type
LCD TFT
Diagonal
55 "
Maximum resolution
3840x2160 Dots
Aspect Ratio
16:9
Brightness
500 Cd/m2
Contrast Ratio
4000~1
Touch Screen
Touch Screen Type
Capacitive
LED / Controls
LED
Power LED
Controls
On/Off, KeyPad
Connectors
Connectors
DB9, DVI-D, DB15 VGA, 2xHDMI, 1xUSB, Display Port, DC input (terminal block)
System Power Input
Input Voltage DC
9..36 V
Power Consumption
140 W
Power Supply
Type of Power Supply
External power adapter AC/DC
Operating Conditions
Operating Temperature
-15..55 °C
Humidity
5-95%
Vibration
0.7g@DNVGL CG-0339 (Class A)
Shock
15G,11ms duration
Dimensions and weight
Width
1273 mm
Height
744.6 mm
Depth
62.5 mm
Standards and Certifications
Certifications
CE, FCC
