W43L100-MLA2FP
Winmate
SKU: 80191200
42.5" Military Display, MIL-STD-810H/461G Certification, 3840 x 2160, 350 cd/m2, PCAP Touch, DP, DVI, VGA, 2xHDMI Opt., Optional: (USB, COM, Audio), 100-240VAC-in (9-36VDC-in Optional)
Price on request
Available
Available
Construction
Construction Chassis
Metal Chassis
Mounting Configuration
19" Rackmount, Wall VESA 100, VESA 200
Display
Display Type
LCD TFT
Diagonal
42.5 "
Maximum resolution
3840x2160 Dots
Aspect Ratio
16:9
Brightness
500 Cd/m2
Contrast Ratio
5000~1
Input Interface
DisplayPort, VGA, DVI
Touch Screen
Touch Screen Type
Capacitive
Interface
USB
LED / Controls
LED
Power LED
Controls
On/Off, KeyPad
Connectors
Connectors
DVI, DB15 VGA, 1xUSB, DC Input, Display Port
System Power Input
Input Voltage AC
100..240 V
Power Supply
Type of Power Supply
Internal
Input Voltage AC
100..240 V
Operating Conditions
Operating Temperature
0..50 °C
Humidity
10-95%
Dimensions and weight
Width
1088.2 mm
Height
681.4 mm
Depth
84.6 mm
Standards and Certifications
Certifications
CE/FCC
MIL-STD-810
MIL-STD-810G Test Method 514.6 Vibration, MIL-STD-810G Test Method 516.6 Shock
Dimensions
Net Weight
24.5 kg
Gross Weight
27 kg
Construction
Construction Chassis
Metal Chassis
Mounting Configuration
19" Rackmount, Wall VESA 100, VESA 200
Display
Display Type
LCD TFT
Diagonal
42.5 "
Maximum resolution
3840x2160 Dots
Aspect Ratio
16:9
Brightness
500 Cd/m2
Contrast Ratio
5000~1
Input Interface
DisplayPort, VGA, DVI
Touch Screen
Touch Screen Type
Capacitive
Interface
USB
LED / Controls
LED
Power LED
Controls
On/Off, KeyPad
Connectors
Connectors
DVI, DB15 VGA, 1xUSB, DC Input, Display Port
System Power Input
Input Voltage AC
100..240 V
Power Supply
Type of Power Supply
Internal
Input Voltage AC
100..240 V
Operating Conditions
Operating Temperature
0..50 °C
Humidity
10-95%
Dimensions and weight
Width
1088.2 mm
Height
681.4 mm
Depth
84.6 mm
Standards and Certifications
Certifications
CE/FCC
MIL-STD-810
MIL-STD-810G Test Method 514.6 Vibration, MIL-STD-810G Test Method 516.6 Shock
Dimensions
Net Weight
24.5 kg
Gross Weight
27 kg
Construction
Construction Chassis
Metal Chassis
Mounting Configuration
19" Rackmount, Wall VESA 100, VESA 200
Display
Display Type
LCD TFT
Diagonal
42.5 "
Maximum resolution
3840x2160 Dots
Aspect Ratio
16:9
Brightness
500 Cd/m2
Contrast Ratio
5000~1
Input Interface
DisplayPort, VGA, DVI
Touch Screen
Touch Screen Type
Capacitive
Interface
USB
LED / Controls
LED
Power LED
Controls
On/Off, KeyPad
Connectors
Connectors
DVI, DB15 VGA, 1xUSB, DC Input, Display Port
System Power Input
Input Voltage AC
100..240 V
Power Supply
Type of Power Supply
Internal
Input Voltage AC
100..240 V
Operating Conditions
Operating Temperature
0..50 °C
Humidity
10-95%
Dimensions and weight
Width
1088.2 mm
Height
681.4 mm
Depth
84.6 mm
Standards and Certifications
Certifications
CE/FCC
MIL-STD-810
MIL-STD-810G Test Method 514.6 Vibration, MIL-STD-810G Test Method 516.6 Shock
Dimensions
Net Weight
24.5 kg
Gross Weight
27 kg
Construction
Construction Chassis
Metal Chassis
Mounting Configuration
19" Rackmount, Wall VESA 100, VESA 200
Display
Display Type
LCD TFT
Diagonal
42.5 "
Maximum resolution
3840x2160 Dots
Aspect Ratio
16:9
Brightness
500 Cd/m2
Contrast Ratio
5000~1
Input Interface
DisplayPort, VGA, DVI
Touch Screen
Touch Screen Type
Capacitive
Interface
USB
LED / Controls
LED
Power LED
Controls
On/Off, KeyPad
Connectors
Connectors
DVI, DB15 VGA, 1xUSB, DC Input, Display Port
System Power Input
Input Voltage AC
100..240 V
Power Supply
Type of Power Supply
Internal
Input Voltage AC
100..240 V
Operating Conditions
Operating Temperature
0..50 °C
Humidity
10-95%
Dimensions and weight
Width
1088.2 mm
Height
681.4 mm
Depth
84.6 mm
Standards and Certifications
Certifications
CE/FCC
MIL-STD-810
MIL-STD-810G Test Method 514.6 Vibration, MIL-STD-810G Test Method 516.6 Shock
Dimensions
Net Weight
24.5 kg
Gross Weight
27 kg
