tSH-724

tSH-724

ICP DAS
SKU: 06839800
Tiny Serial Port Sharer with PoE, 1 RS-232 and 1 RS-485 Ports Ports
Price on request
Available on order
Available on order
Ethernet
Total Ethernet
1
10/100 Mbit/s
1
Type 10/100 Mbit/s
RJ-45
Interfaces
COM Total
2
RS-232
1
RS-485
1
LED / Controls
Setup of Operation Mode
Web-interface
Connectors
Connectors
Terminal block
System Power Input
Input Voltage DC
12..48 V
Power over Ethernet (PoE)
IEEE 802.3af, PoE
Operating Conditions
Operating Temperature
-25..75 °C
Construction
Construction Chassis
Plastic Chassis
Mounting Configuration
DIN-Rail mount
Dimensions and weight
Width
52 mm
Depth
27 mm
Height
95 mm
Dimensions
Net Weight
0.16 kg
Gross Weight
0.14 kg
Ethernet
Total Ethernet
1
10/100 Mbit/s
1
Type 10/100 Mbit/s
RJ-45
Interfaces
COM Total
2
RS-232
1
RS-485
1
LED / Controls
Setup of Operation Mode
Web-interface
Connectors
Connectors
Terminal block
System Power Input
Input Voltage DC
12..48 V
Power over Ethernet (PoE)
IEEE 802.3af, PoE
Operating Conditions
Operating Temperature
-25..75 °C
Construction
Construction Chassis
Plastic Chassis
Mounting Configuration
DIN-Rail mount
Dimensions and weight
Width
52 mm
Depth
27 mm
Height
95 mm
Dimensions
Net Weight
0.16 kg
Gross Weight
0.14 kg
Ethernet
Total Ethernet
1
10/100 Mbit/s
1
Type 10/100 Mbit/s
RJ-45
Interfaces
COM Total
2
RS-232
1
RS-485
1
LED / Controls
Setup of Operation Mode
Web-interface
Connectors
Connectors
Terminal block
System Power Input
Input Voltage DC
12..48 V
Power over Ethernet (PoE)
IEEE 802.3af, PoE
Operating Conditions
Operating Temperature
-25..75 °C
Construction
Construction Chassis
Plastic Chassis
Mounting Configuration
DIN-Rail mount
Dimensions and weight
Width
52 mm
Depth
27 mm
Height
95 mm
Dimensions
Net Weight
0.16 kg
Gross Weight
0.14 kg
Ethernet
Total Ethernet
1
10/100 Mbit/s
1
Type 10/100 Mbit/s
RJ-45
Interfaces
COM Total
2
RS-232
1
RS-485
1
LED / Controls
Setup of Operation Mode
Web-interface
Connectors
Connectors
Terminal block
System Power Input
Input Voltage DC
12..48 V
Power over Ethernet (PoE)
IEEE 802.3af, PoE
Operating Conditions
Operating Temperature
-25..75 °C
Construction
Construction Chassis
Plastic Chassis
Mounting Configuration
DIN-Rail mount
Dimensions and weight
Width
52 mm
Depth
27 mm
Height
95 mm
Dimensions
Net Weight
0.16 kg
Gross Weight
0.14 kg
Documentation
Configuration tSH-735 RUS tSH-700 Datasheet tSH-7xx User Manual tSH-700 Firmware Upgrade Guide
Software
eSearch Utility Firmware for tSH-700 revB/revB2 (Dec. 2023)
Documentation
Configuration tSH-735 RUS tSH-700 Datasheet tSH-7xx User Manual tSH-700 Firmware Upgrade Guide
Software
eSearch Utility Firmware for tSH-700 revB/revB2 (Dec. 2023)
Documentation
Configuration tSH-735 RUS tSH-700 Datasheet tSH-7xx User Manual tSH-700 Firmware Upgrade Guide
Software
eSearch Utility Firmware for tSH-700 revB/revB2 (Dec. 2023)
Documentation
Configuration tSH-735 RUS tSH-700 Datasheet tSH-7xx User Manual tSH-700 Firmware Upgrade Guide
Software
eSearch Utility Firmware for tSH-700 revB/revB2 (Dec. 2023)
