NPort IA-5150-T-IEX

MOXA
SKU: 06321400
1-Port RS-232/422/485 Serial Device Server, 2x10/100 Base-T(X) (RJ45, Single IP), IECEx
End-of-life product

Ethernet
Total Ethernet
2
10/100 Mbit/s
2
Type 10/100 Mbit/s
2xRJ-45
Interfaces
COM Total
1
RS-232/422/485
1
LED / Controls
LED
READY LED, PWR1, PWR2, COM-ports LED
Setup of Operation Mode
Telnet, Via COM-port, Web-interface
Controls
1xReset
Construction
Construction Chassis
Plastic Chassis
Mounting Configuration
DIN-Rail mount
Protection Level of Chassis
IP30
Dimensions and weight
Width
29 mm
Depth
89.2 mm
Height
118.5 mm
Standards and Certifications
EMI
EN 55022 Class A, FCC Part 15 Subpart B Class A
EMS
EN 55024, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 61000-4-11
Explosion safety
IECEx
Freefall
IEC 60068-2-32
Marine grade
DNV
Oil And Gas
Class I Div.2 Groups A, B, C, D, ATEX Zone 2 Ex nC IIC
Safety
UL 60950-1, UL 508, EN 60950-1
Vibration And Shock
IEC 60068-2-6, IEC 60068-2-27
Dimensions
Gross Weight
0.38 kg
