1U Rackmount Processor-based Platform, Intel Atom C3958 2.0GHz, up to 64GB DDR4 2133/2400MHz, 4xLAN, 1xNMC, 2xUSB 3.0, 2xMGM, PSU 150W AC-in
FWA-2012-12A1S
Advantech
SKU: 07832100
Price on request
Available on order
Available on order
Construction
Construction Chassis
Heavy-Duty Steel Chassis
Mounting Configuration
19" Rackmount
Height
1 U
Type
Fans
CPU
Processor Installed
Intel Atom C3958
Socket
CPU onboard
Max CPU frequency
2 GHz
Memory
Form-factor
DDR4
Socket Type
2xDIMM
ECC
Yes
Maximum Memory
64 GB
Assembly
Removable
Ethernet
Controller Type
Intel i210 10/100/1000 Mbps, Marvell 88E1543 10/100/1000 Mbps
Total Ethernet
6
10/100/1000 Mbit/s
6
Interfaces
USB Total
2
USB v3.x
2
Drive interfaces
mSATA
1
Storage Cage
Number Of Cage External
1
3.5" Cage Intenal
1
Extension Slots
Total
3
M.2
2
LED / Controls
LED
1xHDD LED, 1xOn/Off LED
Controls
Control Buttons
System Power Input
Input Voltage AC
100..240 V
Software
Operating System Compatibility
Linux OS
Dimensions and weight
Width
430 mm
Height
44 mm
Depth
320.7 mm
Operating Conditions
Operating Temperature
0..40 °C
Vibration
0.5 Grms, 5-500Hz, 1hr/axis
Shock
10G, 11ms
Standards and Certifications
Certifications
CE, FCC
Dimensions
Net Weight
6.6 kg
Gross Weight
7 kg
