EDS-308-SS-SC-T

Industrial switch EDS-308-SS-SC-T is a great choice of an unmanaged switch for integration of several industrial network segments. The design features 6 10/100 Base TX ports with RJ-45 slots and 2 100 Base FX optical ports with modern slots, which are provided for data transfer over a single-mode fiber optic cable with the best communication distance values, throughput and noise interference protection. The switch is capable of operation at extreme temperatures and is equipped with a dual power circuit. Network switch EDS-308-SS-SC-T: description and features: Single-mode optical fiber allows transmitting large data packets over distances of up to 40 km. There is minimum dispersion and signal attenuation. Wave length: 1310 nm. Max TX: 0 dBm. Min TX: -5 dBm. There is a built-in protection against broadcast storms and a discrete output relay channel for alerting to power failures or communication disruptions. A redundant power circuit automatically activates a backup accumulator, if the main power source fails. The device requires not more than 6 W at 24 V. The operating temperature range: -40…+75 °C. It allows you to design networks for operation in any weather and industrial conditions. The robust industrial grade chassis that conforms to IP30 standard is compact in size and protects the electronic components from drops, vibrations and shocks (МЭК-60068/IEC 60068). The device can be mounted either on a wall, or a DIN-rail. Mean time between failures (MTBF) - over 30 years. Ethernet switch EDS-308-SS-SC-T by MOXA can function in either of two modes, it allows using Store and Forward switching method and provides high level of protection on hardware and software levels. The design and assembly quality of the device are testified by certificates on transport, marine and oil and gas industry application.
