AWK-4262A-UN-T

AWK-4262A-UN-T

MOXA
SKU: 80235300
Advanced industrial outdoor Wi-Fi 6 wireless AP/bridge/client, IP68, 1x10/100/1000/2500Base-TX M12, 1x10/100/1000Base-TX M12, 2xN-type, 1xUSB, 12..48 VDC, Operating Temperature -40..75 C
Price on request
Available
Available

Ethernet
Total Ethernet
2
Type 10/100/1000 Mbit/s
RJ-45
Type 2,5 Gbit/s
RJ-45
PoE+ 10/100/1000 Mbit/s
1
Wi-Fi
Wi-Fi Standard
802.11a/b/g/n/ac/ax
Quantity of Wi-Fi
1
Supported Protocols
Managment Protocols
DHCP Server/Client, SMTP, SNMPv1/v2c/v3, LLDP, Syslog, UDP, DNS, VLAN, TCP/IP
Security Protocols
HTTPS, SSH, RADIUS, SSL
IEEE Standard
ieee_802.3u, ieee_802.3ab, ieee_802.3at, ieee_802.3, ieee_802.1x, IEEE 802.3az for Energy-Efficient Ethernet, IEEE 802.3bz for 2.5GBaseX, IEEE 802.3bt for Power over Ethernet
Digital Output
Total channels of digital output
2
Type
Electromagnitic relay
Contact rating of relay (Form A)
1A@24V DC
LED / Controls
LED
Power LED, PoE LED, PWR1, PWR2
Controls
1xReset
Setup of Operation Mode
Telnet, Console Port, Web-interface
Connectors
Connectors
Console Port RS-232 (RJ-45)
Construction
Construction Chassis
Metal Chassis
Mounting Configuration
DIN-Rail mount
Protection Level of Chassis
IP68
Type
Fanless
Dimensions and weight
Width
65.9 mm
Depth
157.6 mm
Height
244 mm
Operating Conditions
Operating Temperature
-40..75 °C
Humidity
5-95%
MTBF
2376815 h
Standards and Certifications
EMI
CISPR 32, FCC Part 15B Class A
EMS
IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8
Radio
FCC
Safety
UL 62368-1, IEC 62368-1
Dimensions
Net Weight
0.76 kg
Gross Weight
1.2 kg
