WDAP-5100BE

WDAP-5100BE

Planet
SKU: 80204400
Outdoor Wireless Access Point, IP67, 1x10/100/1000Base-T, 1x10/100/1000/2500Base-T with PoE, Operating Temperature -40..70 C
Price on request
Available
Available

Ethernet
Total Ethernet
2
10/100/1000 Mbit/s
1
2,5 Gbit/s
1
PoE+ 10/100/1000 Mbit/s
1
Wi-Fi
Wi-Fi Standard
802.11k, 802.11r, 802.11v, 802.11i, 802.11a/b/g/n/ac/ax, 802.11be
Wi-Fi Operation Mode
Access point
Security
WPA, WPA2, WPA3, WPA2-Enterprise
Supported Protocols
Managment Protocols
Syslog, DHCP, DDNS, IGMP
Security Protocols
RADIUS, PPTP, L2TP, PPPoE
IEEE Standard
IEEE 802.3 for 10BaseT, IEEE 802.3ab for 1000BaseT(X), IEEE 802.3af/at for Power-over-Ethernet, IEEE 802.3x for Flow Control, IEEE 802.3u for 100BaseT(X), IEEE 802.3bz for 2.5GBaseX
Construction
Construction Chassis
Aluminium Chassis
Protection Level of Chassis
IP67
Dimensions and weight
Width
243.16 mm
Depth
218.26 mm
Height
64.04 mm
Operating Conditions
Operating Temperature
-40..70 °C
Humidity
10-90%
Standards and Certifications
Certifications
CE
Dimensions
Net Weight
2 kg
Gross Weight
2.5 kg
Ethernet
Total Ethernet
2
10/100/1000 Mbit/s
1
2,5 Gbit/s
1
PoE+ 10/100/1000 Mbit/s
1
Wi-Fi
Wi-Fi Standard
802.11k, 802.11r, 802.11v, 802.11i, 802.11a/b/g/n/ac/ax, 802.11be
Wi-Fi Operation Mode
Access point
Security
WPA, WPA2, WPA3, WPA2-Enterprise
Supported Protocols
Managment Protocols
Syslog, DHCP, DDNS, IGMP
Security Protocols
RADIUS, PPTP, L2TP, PPPoE
IEEE Standard
IEEE 802.3 for 10BaseT, IEEE 802.3ab for 1000BaseT(X), IEEE 802.3af/at for Power-over-Ethernet, IEEE 802.3x for Flow Control, IEEE 802.3u for 100BaseT(X), IEEE 802.3bz for 2.5GBaseX
Construction
Construction Chassis
Aluminium Chassis
Protection Level of Chassis
IP67
Dimensions and weight
Width
243.16 mm
Depth
218.26 mm
Height
64.04 mm
Operating Conditions
Operating Temperature
-40..70 °C
Humidity
10-90%
Standards and Certifications
Certifications
CE
Dimensions
Net Weight
2 kg
Gross Weight
2.5 kg
Ethernet
Total Ethernet
2
10/100/1000 Mbit/s
1
2,5 Gbit/s
1
PoE+ 10/100/1000 Mbit/s
1
Wi-Fi
Wi-Fi Standard
802.11k, 802.11r, 802.11v, 802.11i, 802.11a/b/g/n/ac/ax, 802.11be
Wi-Fi Operation Mode
Access point
Security
WPA, WPA2, WPA3, WPA2-Enterprise
Supported Protocols
Managment Protocols
Syslog, DHCP, DDNS, IGMP
Security Protocols
RADIUS, PPTP, L2TP, PPPoE
IEEE Standard
IEEE 802.3 for 10BaseT, IEEE 802.3ab for 1000BaseT(X), IEEE 802.3af/at for Power-over-Ethernet, IEEE 802.3x for Flow Control, IEEE 802.3u for 100BaseT(X), IEEE 802.3bz for 2.5GBaseX
Construction
Construction Chassis
Aluminium Chassis
Protection Level of Chassis
IP67
Dimensions and weight
Width
243.16 mm
Depth
218.26 mm
Height
64.04 mm
Operating Conditions
Operating Temperature
-40..70 °C
Humidity
10-90%
Standards and Certifications
Certifications
CE
Dimensions
Net Weight
2 kg
Gross Weight
2.5 kg
Ethernet
Total Ethernet
2
10/100/1000 Mbit/s
1
2,5 Gbit/s
1
PoE+ 10/100/1000 Mbit/s
1
Wi-Fi
Wi-Fi Standard
802.11k, 802.11r, 802.11v, 802.11i, 802.11a/b/g/n/ac/ax, 802.11be
Wi-Fi Operation Mode
Access point
Security
WPA, WPA2, WPA3, WPA2-Enterprise
Supported Protocols
Managment Protocols
Syslog, DHCP, DDNS, IGMP
Security Protocols
RADIUS, PPTP, L2TP, PPPoE
IEEE Standard
IEEE 802.3 for 10BaseT, IEEE 802.3ab for 1000BaseT(X), IEEE 802.3af/at for Power-over-Ethernet, IEEE 802.3x for Flow Control, IEEE 802.3u for 100BaseT(X), IEEE 802.3bz for 2.5GBaseX
Construction
Construction Chassis
Aluminium Chassis
Protection Level of Chassis
IP67
Dimensions and weight
Width
243.16 mm
Depth
218.26 mm
Height
64.04 mm
Operating Conditions
Operating Temperature
-40..70 °C
Humidity
10-90%
Standards and Certifications
Certifications
CE
Dimensions
Net Weight
2 kg
Gross Weight
2.5 kg

Documentation
WDAP-5100BE-Datasheet.pdf WDAP-5100BE-User-Manual.pdf
Documentation
WDAP-5100BE-Datasheet.pdf WDAP-5100BE-User-Manual.pdf
Documentation
WDAP-5100BE-Datasheet.pdf WDAP-5100BE-User-Manual.pdf
Documentation
WDAP-5100BE-Datasheet.pdf WDAP-5100BE-User-Manual.pdf
