IAP-3600BE

IAP-3600BE

Planet
SKU: 80148900
Industrial Dual Band Wireless Access Point, 5x10/100/1000Base-T RJ45 Ports, 1xUSB, 2xDI, 2xDO, 9..54V DC, -40..70C Operating Temperature
Price on request
Available
Available
Ethernet
Total Ethernet
5
10/100/1000 Mbit/s
5
Interfaces
USB Total
1
Supported Protocols
Managment Protocols
SNMPv1/v2c/v3, DDNS, IGMP
Security Protocols
PPTP, L2TP, PPPoE
Digital Input
Total channels of digital input
2
Digital Output
Total channels of digital output
2
System Power Input
Input Voltage DC
9..54 V
Construction
Protection Level of Chassis
IP30
Dimensions and weight
Width
50 mm
Depth
135 mm
Height
135 mm
Operating Conditions
Operating Temperature
-40..70 °C
Humidity
5-90%
Standards and Certifications
Certifications
CE
EMI
FCC Part 15 Subpart B Class A
Dimensions
Net Weight
0.88 kg
Gross Weight
1.29 kg
