VTC-7251-7C4
NEXCOM
SKU: 08738600
Vehicle Telematics Computer with Intel 8th Gen i7-8700T 2.4GHz CPU, 8GB DDR4, VGA, HDMI, 4x1000 PoE 802.3af/at, 1x1000 Mbps LAN, 2xRS232, 1xRS232/422/485, 4xUSB, Audio, 2x2.5" SATA Drive Bay, 2x mSATA, 4xMini-PCIe, M.2 key B, CANBus, 9-36V DC-In
Price on request
Available on order
Available on order
Construction
Construction Chassis
Aluminium Chassis
Mounting Configuration
Embedded
Type
Fanless
CPU
Processor Installed
Intel Core i7-8700T
Max CPU frequency
4 GHz
Chipset
Chipset
Intel Q370
Memory
Form-factor
DDR4
Default on Board Memory
8 GB
Maximum Memory
32 GB
Assembly
Removable
Ethernet
Total Ethernet
5
10/100/1000 Mbit/s
5
Interfaces
COM Total
2
RS-232
1
RS-422/485
1
USB Total
4
USB 2.0
4
Digital Input
Isolation DIO
Yes
Drive interfaces
RAID Levels
1, 5, 10
mSATA
1
Storage Cage
Number Of Cage External
2
2.5" Cage External
2
Extension Slots
Total
4
M.2
1
Mini-PCIe/Mini Card
4
SIM Card slots
3
Antenna characteristics
Cellular interfaces
3G (Optional)
Connectors
Connectors
2xDB9, DB15 VGA, HDMI, 3xUSB, Mic In, Line Out, DC Input, DB9 GPIO, 12V DC Output, 9xRJ45 Ethernet
System Power Input
Input Voltage DC
9..36 V
Software
Operating System Compatibility
Linux OS, Windows 10
Dimensions and weight
Width
260 mm
Height
99 mm
Depth
196 mm
Operating Conditions
Operating Temperature
-30..60 °C
Vibration
SSD: 1g @ 5..500 Hz
Shock
20g
Standards and Certifications
Certifications
CE, FCC Class A
MIL-STD-810
MIL-STD-810G Test Method 514.6 Vibration, MIL-STD-810G Test Method 516.6 Shock
Automotive
e13 Mark
Dimensions
Net Weight
4.2 kg
Gross Weight
5.8 kg
