nROK-7271-WI-H
NEXCOM
SKU: 57787800
Railway Fanless PC, Intel 12th/13th Gen CPU, R680E, Up to 64GB DDR5 RAM, VGA, HDMI, 2x2.5GbE M12 LAN, 2xCOM, 2xUSB 3.2, 2xUSB 2.0 (M12), 1xDB15 CAN/DIO, 2xSIM, 2x2.5" Drive Bay, 2xMiniPCIe/mSATA, 5xM.2, GPS, TPM 2.0, MicroSD, 24-110VDC-in, -35..70C
Price on request
Available
Available
Construction
Construction Chassis
Aluminium Chassis
Mounting Configuration
Embedded, Desktop, Wall
Type
Fanless
CPU
СPU Generation/Family
Alder Lake, Raptor Lake
Socket
LGA1700
Chipset
Chipset
Intel R680E
Memory
Socket Type
2xSODIMM
ECC
Yes
Maximum Memory
64 GB
Assembly
Removable
Graphic
Graphic Controller
Integrated in CPU, Intel UHD Graphics
Ethernet
Controller Type
Intel i226-LM
Total Ethernet
2
2,5 Gbit/s
2
Wi-Fi
Wi-Fi Standard
Yes
Interfaces
COM Total
2
RS-232/422/485
2
USB Total
4
USB 2.0
2
Digital Input-Output
Channels of DIO
8
Isolation DIO
Yes
Industrial Interfaces
CAN Port
2
Drive interfaces
RAID Levels
1
Storage Cage
Number Of Cage External
2
2.5" Cage External
2
Extension Slots
Total
7
M.2
5
Mini-PCIe/Mini Card
2
Connectors
Connectors
2xDB9, DB15 VGA, HDMI, 2xUSB, SIM Card Slot, DB15 CAN Bus, M12 USB, MicroSD card slot, M12 DC-in, 2xM12 LAN, M8 Audio
Software
Operating System Compatibility
Linux OS, Windows 10, Windows 11
Dimensions and weight
Width
260 mm
Height
110 mm
Depth
210 mm
Operating Conditions
Vibration
Vibration (random) - 2g@5~500 Hz (in operation, SSD); Vibration (SSD) - Operating: MIL-STD-810H, Method 514.8C, Procedure 1, Category 4, common carrier US highway truck vibration exposure - Storage: MIL-STD-810H, Method 514.8E, Procedure 1, Category 24,
Shock
Operating: MIL-STD-810H, Method 516.8, Procedure I, functional shock=40g; Non-operating: MIL-STD-810H, Method 516.8, Procedure V, crash hazard shock test=75g
Standards and Certifications
Certifications
CE, FCC Class A
MIL-STD-810
MIL-STD-810H Test Method 516.8 Shock, MIL-STD-810H Test Method 514.8 Vibration
Rolling Stock
EN 50155, EN 45545
Automotive
e13 Mark
Dimensions
Net Weight
6.4 kg
Gross Weight
7.2 kg
Construction
Construction Chassis
Aluminium Chassis
