NA350C

AXIOMTEK
SKU: 09905100
1U network appliance with Intel Atom x6425E processor, DDR4, HDMI, 2xGbE RJ45 LAN, 2x1G SFP, 3x2.5GbE RJ45 LAN, 2xUSB 2.0, M.2 Key M 2242, M.2 Bey B 3052/3042, M.2 Key E 2230
Price on request
Available
Available

Construction
Construction Chassis
Heavy-Duty Steel Chassis
Mounting Configuration
Desktop
Height
1 U
CPU
СPU Generation/Family
Elkhart Lake
Processor Installed
Atom x6425E
Socket
CPU onboard
Max CPU frequency
3 GHz
Chipset
Chipset
Intel Atom SoC
Memory
Socket Type
2xSODIMM
Maximum Memory
32 GB
Assembly
Removable
Ethernet
Total Ethernet
7
Interfaces
USB Total
2
USB 2.0
2
Drive interfaces
M.2
1
Extension Slots
Total
5
M.2
3
Mini-PCIe/Mini Card
2
LED / Controls
LED
1xHDD LED, Power LED, BYPASS LED
Controls
On/Off, 1xReset
Connectors
Connectors
HDMI, 5xRJ45 Ethernet, 2xUSB, DC Input, 2xSFP, RJ45 (Console)
System Power Input
Input Voltage DC
12..12 V
Power Supply
Type of Power Supply
External power adapter AC/DC
Output Power
60 W
Software
Operating System Compatibility
Linux OS
Dimensions and weight
Width
257 mm
Height
44 mm
Depth
197 mm
Operating Conditions
Operating Temperature
0..40 °C
Standards and Certifications
Certifications
CE, FCC Class B
Dimensions
Net Weight
1.6 kg
Gross Weight
2.45 kg
