ISA-140
NEXCOM
SKU: 57289500
Fanless Industrial Security DIN Appliance, Intel Atom x6212RE CPU, 1xDDR4 SO-DIMM up to 16GB, eMMC up to 8GB, HDMI, 6xGbE, 4xSMA, 2xUSB, 2xM.2 Key-B, 9..36VDC, -30..75C
Price on request
Available
Available
The ISA 140 from NEXCOM is a compact, fanless industrial security appliance powered by Intel’s latest dual-core Atom® processor. It features six 1GbE ports for network connectivity and supports seamless Wi-Fi/LTE connectivity along with out-of-band (OOB) remote management. Designed to operate in environments with wide temperature ranges, its compact DIN rail form factor makes it easy for IT personnel to integrate the ISA 140 into existing network infrastructures without disrupting the productivity of manufacturing equipment.
The ISA 140 from NEXCOM is a compact, fanless industrial security appliance powered by Intel’s latest dual-core Atom® processor. It features six 1GbE ports for network connectivity and supports seamless Wi-Fi/LTE connectivity along with out-of-band (OOB) remote management. Designed to operate in environments with wide temperature ranges, its compact DIN rail form factor makes it easy for IT personnel to integrate the ISA 140 into existing network infrastructures without disrupting the productivity of manufacturing equipment.
CPU
СPU Generation/Family
Elkhart Lake
Processor Installed
Atom x6212RE
Memory
Form-factor
DDR4
Socket Type
1xSODIMM
Maximum Memory
16 GB
Ethernet
10/100/1000 Mbit/s
6
Interfaces
USB v3.x
2
Drive interfaces
M.2
2
Extension Slots
SIM Card slots
1, Micro-SIM
Connectors
Connectors
1xUSB, SIM Card Slot, SMA Female, 7xRJ45 Ethernet
Power Supply
Input Voltage DC
9..36 V
Dimensions and weight
Width
165 mm
Height
61.7 mm
Depth
129.25 mm
Operating Conditions
Operating Temperature
-30..70 °C
Humidity
5-95%
Standards and Certifications
Certifications
CE, FCC Class A
Dimensions
Net Weight
1.3 kg
Gross Weight
2.19 kg
CPU
СPU Generation/Family
Elkhart Lake
Processor Installed
Atom x6212RE
Memory
Form-factor
DDR4
Socket Type
1xSODIMM
Maximum Memory
16 GB
Ethernet
10/100/1000 Mbit/s
6
Interfaces
USB v3.x
2
Drive interfaces
M.2
2
Extension Slots
SIM Card slots
1, Micro-SIM
Connectors
Connectors
1xUSB, SIM Card Slot, SMA Female, 7xRJ45 Ethernet
Power Supply
Input Voltage DC
9..36 V
Dimensions and weight
Width
165 mm
Height
61.7 mm
Depth
129.25 mm
Operating Conditions
Operating Temperature
-30..70 °C
Humidity
5-95%
Standards and Certifications
Certifications
CE, FCC Class A
Dimensions
Net Weight
1.3 kg
Gross Weight
2.19 kg
CPU
СPU Generation/Family
Elkhart Lake
Processor Installed
Atom x6212RE
Memory
Form-factor
DDR4
Socket Type
1xSODIMM
Maximum Memory
16 GB
Ethernet
10/100/1000 Mbit/s
6
Interfaces
USB v3.x
2
Drive interfaces
M.2
2
Extension Slots
SIM Card slots
1, Micro-SIM
Connectors
Connectors
1xUSB, SIM Card Slot, SMA Female, 7xRJ45 Ethernet
Power Supply
Input Voltage DC
9..36 V
Dimensions and weight
Width
165 mm
Height
61.7 mm
Depth
129.25 mm
Operating Conditions
Operating Temperature
-30..70 °C
Humidity
5-95%
Standards and Certifications
Certifications
CE, FCC Class A
Dimensions
Net Weight
1.3 kg
Gross Weight
2.19 kg
CPU
СPU Generation/Family
Elkhart Lake
Processor Installed
Atom x6212RE
Memory
Form-factor
DDR4
Socket Type
1xSODIMM
Maximum Memory
16 GB
Ethernet
10/100/1000 Mbit/s
6
Interfaces
USB v3.x
2
Drive interfaces
M.2
2
Extension Slots
SIM Card slots
1, Micro-SIM
Connectors
Connectors
1xUSB, SIM Card Slot, SMA Female, 7xRJ45 Ethernet
Power Supply
Input Voltage DC
9..36 V
Dimensions and weight
Width
165 mm
Height
61.7 mm
Depth
129.25 mm
Operating Conditions
Operating Temperature
-30..70 °C
Humidity
5-95%
Standards and Certifications
Certifications
CE, FCC Class A
Dimensions
Net Weight
1.3 kg
Gross Weight
2.19 kg
