MBD-X12SCQ-B
Super Micro Computer, B.V. NL
SKU: 57345800
Micro-ATX Motherboard, Intel 10th Gen Core i9/i7/i5/i3 LGA1200 CPU, TDP 125W, Intel Q470E Chipset, Up to 128GB ECC/non-ECC DDR4 DIMM, HDMI/DP/DVI-D/VGA, 6xSATA, 2xGbE LAN, 6xUSB 2.0, 6xUSB 3.1, 1xM.2 Key M, 2xPCIe x4, 1xPCIe x16, 1xPCIe x8, 0..60C
Price on request
Available
Available
System Architecture
Form Factor
Micro ATX
CPU
СPU Generation/Family
Comet Lake
Socket
LGA1200
Chipset
Chipset
Intel Q470E
Memory
Socket Type
4xDIMM
ECC
No
Maximum Memory
128 GB
Assembly
Removable
Graphic
Graphic Controller
Integrated in CPU
Interfaces
DisplayPort, DVI-D, HDMI, VGA
Ethernet
Controller Type
Intel i210-AT, Intel i219-LM
Total Ethernet
2
10/100/1000 Mbit/s
2
Interfaces
COM Total
4
USB Total
12
USB 2.0
6
Audio
Audio Controller
Realtek ALC888S
Drive interfaces
RAID Levels
1, 5, 10
Extension Slots
PCI Express x16
1
PCI Express x8
1
PCI Express x4
2
M.2
1
Connectors
Internal Ports
COM, 6xSATA 3
Connectors
24pin ATX, DVI-D, DB15 VGA, HDMI, PS/2 Keyboard/Mouse, 2xRJ45 Ethernet, 4xUSB, Mic In, Line In, Line Out, Display Port, 8-pin ATX, USB type C
Dimensions and weight
Width
243.8 mm
Length
243.8 mm
Dimensions
Net Weight
0.5 kg
Gross Weight
1.5 kg
