DGW-A16X-1-1201-C6

DGW-A16X-1-1201-C6

Kyland
SKU: 09931400
Industrial DIN-Rail protocol gateways for Smart Grid, IEC 101/104/DNP3/Modbus/MMS, 8xRS-232/485, 8xRS-485, 4xLAN, 85-264 VAC/100-300 VDC, DIN Rail, MMS Client, -40...+85C
Price on request
Available on order
Available on order
Ethernet
Total Ethernet
4
10/100 Mbit/s
4
Interfaces
COM Total
16
RS-485
8
RS-232/485
8
Supported Protocols
Industrial Protocols
Modbus TCP, Modbus RTU, 60870-5-101 master, 60870-5-101 slave, 60870-5-104 client, 60870-5-104 server, DNP3, IEC61850 MMS server, IEC61850 MMS client
Managment Protocols
NTP
Operating Conditions
Operating Temperature
-40..85 °C
Humidity
5-95%
Construction
Construction Chassis
Metal Chassis
Mounting Configuration
19" Rackmount
Dimensions and weight
Width
483 mm
Depth
200 mm
Height
45 mm
Standards and Certifications
Certifications
CE
EMS
IEC 61000-4-2, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-8, IEC 61000-4-9, IEC 61000-4-10, IEC 61000-4-11, IEC 61000-4-12
Safety
EN 60950-1, IEC 60950-1
Dimensions
Net Weight
0.5 kg
Gross Weight
0.7 kg
Ethernet
Total Ethernet
4
10/100 Mbit/s
4
Interfaces
COM Total
16
RS-485
8
RS-232/485
8
Supported Protocols
Industrial Protocols
Modbus TCP, Modbus RTU, 60870-5-101 master, 60870-5-101 slave, 60870-5-104 client, 60870-5-104 server, DNP3, IEC61850 MMS server, IEC61850 MMS client
Managment Protocols
NTP
Operating Conditions
Operating Temperature
-40..85 °C
Humidity
5-95%
Construction
Construction Chassis
Metal Chassis
Mounting Configuration
19" Rackmount
Dimensions and weight
Width
483 mm
Depth
200 mm
Height
45 mm
Standards and Certifications
Certifications
CE
EMS
IEC 61000-4-2, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-8, IEC 61000-4-9, IEC 61000-4-10, IEC 61000-4-11, IEC 61000-4-12
Safety
EN 60950-1, IEC 60950-1
Dimensions
Net Weight
0.5 kg
Gross Weight
0.7 kg
Ethernet
Total Ethernet
4
10/100 Mbit/s
4
Interfaces
COM Total
16
RS-485
8
RS-232/485
8
Supported Protocols
Industrial Protocols
Modbus TCP, Modbus RTU, 60870-5-101 master, 60870-5-101 slave, 60870-5-104 client, 60870-5-104 server, DNP3, IEC61850 MMS server, IEC61850 MMS client
Managment Protocols
NTP
Operating Conditions
Operating Temperature
-40..85 °C
Humidity
5-95%
Construction
Construction Chassis
Metal Chassis
Mounting Configuration
19" Rackmount
Dimensions and weight
Width
483 mm
Depth
200 mm
Height
45 mm
Standards and Certifications
Certifications
CE
EMS
IEC 61000-4-2, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-8, IEC 61000-4-9, IEC 61000-4-10, IEC 61000-4-11, IEC 61000-4-12
Safety
EN 60950-1, IEC 60950-1
Dimensions
Net Weight
0.5 kg
Gross Weight
0.7 kg
Ethernet
Total Ethernet
4
10/100 Mbit/s
4
Interfaces
COM Total
16
RS-485
8
RS-232/485
8
Supported Protocols
Industrial Protocols
Modbus TCP, Modbus RTU, 60870-5-101 master, 60870-5-101 slave, 60870-5-104 client, 60870-5-104 server, DNP3, IEC61850 MMS server, IEC61850 MMS client
Managment Protocols
NTP
Operating Conditions
Operating Temperature
-40..85 °C
Humidity
5-95%
Construction
Construction Chassis
Metal Chassis
Mounting Configuration
19" Rackmount
Dimensions and weight
Width
483 mm
Depth
200 mm
Height
45 mm
Standards and Certifications
Certifications
CE
EMS
IEC 61000-4-2, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-8, IEC 61000-4-9, IEC 61000-4-10, IEC 61000-4-11, IEC 61000-4-12
Safety
EN 60950-1, IEC 60950-1
Dimensions
Net Weight
0.5 kg
Gross Weight
0.7 kg
Documentation
DGW-A8X/DGW-A16X user manual DGW-A8X/DGW-A16X-Datasheet Description of supported protocols
Documentation
DGW-A8X/DGW-A16X user manual DGW-A8X/DGW-A16X-Datasheet Description of supported protocols
Documentation
DGW-A8X/DGW-A16X user manual DGW-A8X/DGW-A16X-Datasheet Description of supported protocols
Documentation
DGW-A8X/DGW-A16X user manual DGW-A8X/DGW-A16X-Datasheet Description of supported protocols
Kyland DGW-A16X-1-1201-00 Industrial DIN-Rail protocol gateways for Smart Grid, IEC 101/104/DNP3/Modbus/MMS, 8xRS-232/485, 8xRS-485, 4xLAN, 85-264 VAC/100-300 VDC, DIN Rail, -40...+85C
Kyland DGW-A16X-1-1201-A4 Industrial DIN-Rail protocol gateways for Smart Grid, IEC 101/104/DNP3/Modbus/MMS, 8xRS-232/485, 8xRS-485, 4xLAN, 85-264 VAC/100-300 VDC, DIN Rail, MMS Server, -40...+85C
Kyland DGW-A16X-1-1201-A5 Industrial DIN-Rail protocol gateways for Smart Grid, IEC 101/104/DNP3/Modbus/MMS, 8xRS-232/485, 8xRS-485, 4xLAN, 85-264 VAC/100-300 VDC, DIN Rail, MMS Client, -40...+85C
Kyland DGW-A16X-1-1201-A6 Industrial DIN-Rail protocol gateways for Smart Grid, IEC 101/104/DNP3/Modbus/MMS, 8xRS-232/485, 8xRS-485, 4xLAN, 85-264 VAC/100-300 VDC, DIN Rail, MMS Client/Server, -40...+85C
Kyland DGW-A16X-1-1201-P0 Industrial DIN-Rail protocol gateways for Smart Grid, IEC 101/104/DNP3/Modbus/MMS, 8xRS-232/485, 8xRS-485, 4xLAN, 85-264 VAC/100-300 VDC, DIN Rail, MMS Client/Server, -40...+85C
