Effective management of modern industrial and mission-critical systems is impossible without accurate and timely data visualization. Reliable, high-quality monitors play a key role in ensuring clear, real-time information display, which is especially important in complex production processes. The Winmate 4K2K series of industrial monitors was designed for the most demanding industries, delivering ultra-high image clarity, resistance to extreme impacts, and uninterrupted operation in mission-critical applications—from production control systems to infrastructure monitoring.
The 4K2K series is designed for industrial automation, transportation, energy, and other applications requiring high reliability, safety, and environmental resistance. These displays deliver exceptional image clarity, secure connectivity, and ruggedness in the most challenging environments.
Key features of Winmate 4K2K industrial monitors
Ultra HD 4K2K display:
Crisp 3840 x 2160 pixel resolution displays detailed data, charts, and analytics with pinpoint accuracy, which is ideal for monitoring complex processes and visualizing large volumes of information.
Operation in extreme conditions:
The new monitors are designed to meet MIL-STD-810G and MIL-STD-461E standards, ensuring resistance to vibration, shock, temperature fluctuations, and electromagnetic interference. This makes them a reliable solution for industrial facilities, including manufacturing plants, power plants, and transportation systems.
Robust housing and reliable connection:
The rugged design supports rack and VESA mounting, providing flexible installation. Industrial-grade MIL-DTL-38999/1 and M12 power connectors ensure stable operation and secure data transfer, even in harsh environments.
Convenient control via physical OSD buttons:
Physical buttons on the case allow you to quickly adjust display settings without the need for additional devices, which is especially important in conditions of intensive use.
Intelligent touchscreen and adaptive brightness:
The capacitive touchscreen (PCAP) ensures precise and responsive operation, even when wearing gloves. A built-in ambient light sensor automatically adjusts brightness, ensuring comfortable viewing in all lighting conditions — from bright sunlight to darkened rooms..
Available models
|
Model name |
Screen diagonal |
Display resolution |
Screen type |
Dimensions |
Interfaces |
|
|
15,6” |
3840x2160 |
Capacitive multitouch |
457,6х287,7х68,8 mm |
VGA, DVI, Display Port |
|
|
23,8” |
3840x2160 |
Capacitive multitouch |
630х430,5х66 mm |
VGA, DVI, Display Port |
|
|
27” |
3840x2160 |
Capacitive multitouch |
697,2x442x73,8 mm |
VGA, DVI, Display Port |
|
|
27” |
3840x2160 |
Antiglare protection glass |
697,2x442x73,9 mm |
VGA, DVI, Display Port |
|
|
32” |
3840x2160 |
Antiglare protection glass |
825x486x88,3 mm |
VGA, DVI, Display Port |
|
|
32” |
3840x2160 |
Capacitive multitouch |
825х486х88,3 mm |
VGA, DVI, Display Port |
|
|
40” |
3840x2160 |
Antiglare protection glass |
978,2х580,4х88,5 mm |
VGA, DVI, Display Port |
|
|
43” |
3840x2160 |
Capacitive multitouch |
1088,2x681,4x84,6 mm |
VGA, DVI, Display Port |
|
|
55” |
3840x2160 |
Capacitive multitouch |
1320x825x85 mm |
VGA, DVI, Display Port |
The Winmate 4K2K series of industrial displays is designed to meet the challenges of today's industry, delivering high image quality, ruggedness and intelligent features for control, monitoring and automation systems.
With a robust design, secure interfaces, and adaptive technologies, these displays ensure stable and reliable operation in any environment. They help optimize production processes, improve equipment control, and enhance overall operational efficiency.
