SPPC-16-10N150
NEXCOM
SKU: 80183400
15.6" Fanless Panel PC, 1920x1080, 450cd/m2, PCAP Touch, Intel N150 CPU, Up to 16GB DDR5 RAM, 2x2.5GbE LAN, 1xUSB 3.2, 3xUSB Type-C, 2xCOM, Audio, 2MP Cam, 1xM.2 Key-M, 1xM.2 Key-B, 1xM.2 Key-E, 20-28VDC-in with 65W Power Adapter
Price on request
Available
Available
Construction
Construction Chassis
Metal Chassis with Aluminium Heatsink
Mounting Configuration
Wall, Wall VESA 100
Type
Fanless
Display
Display Type
LCD TFT
Diagonal
15.6 "
Maximum resolution
1920x1080 Dots
Aspect Ratio
16:9
Brightness
450 Cd/m2
Contrast Ratio
1000~1
Touch Screen
Touch Screen Type
Capacitive
CPU
СPU Generation/Family
Twin Lake
Processor Installed
Intel N150
Socket
FCBGA1264
Max CPU frequency
3.6 GHz
Chipset
Chipset
Intel SoC
Memory
Form-factor
DDR5
Socket Type
1xSODIMM
ECC
No
Maximum Memory
16 GB
Assembly
Removable
Graphic
Graphic Controller
Integrated in CPU
Ethernet
Controller Type
Intel i226V
Total Ethernet
2
2,5 Gbit/s
2
Wi-Fi
Wi-Fi Standard
Yes (Optional)
Interfaces
COM Total
2
RS-232
1
RS-232/422/485
1
USB Total
4
USB v3.x
4
Drive interfaces
M.2
1
Extension Slots
Total
3
M.2
3
M.2 Form Factor
2242 M, 2230 E, 3052 B, 3042 B
SIM Card slots
Yes, 1
Antenna characteristics
Cellular interfaces
4G (Optional)
Connectors
Connectors
2xDB9, 2xRJ45 Ethernet, 1xUSB, Line Out, SIM Card Slot, 3xUSB type C
System Power Input
Input Voltage DC
20..28 V
Power Supply
Type of Power Supply
External power adapter AC/DC
Output Power
65 W
Software
Operating System Compatibility
Linux OS, Windows 10 IoT Enterprise, Windows 10, Windows 11, Windows 11 IoT Enterprise
Dimensions and weight
Width
384.9 mm
Height
234.2 mm
Depth
20 mm
Operating Conditions
Operating Temperature
0..50 °C
Humidity
10-90%
Vibration
Random: 2Grms@5Hz~500Hz, IEC 60068-2-64; Sinusoidal: 2G@5Hz~500Hz, IEC 60068-2-6
Shock
20G peak acceleration, 11ms according to IEC 60068-2-27
Standards and Certifications
Certifications
CE, FCC Class A
EMI
EN 55032, EN 55035
Safety
LVD
Dimensions
Net Weight
5.5 kg
Gross Weight
6.7 kg
