NBP-14210

NBP-14210

SKU: 03578300

1xPICMG, 1xPCI-Express x16, 1xPCI-Express x4, 10xPCI Slots PICMG 1.3 Backplane

Price on request

Backplane

Form Factor

PICMG 1.3 Passive Backplane

Extension Slots

Total

13

PCI Express x16

1

PCI Express x4

1

PICMG

1

PCI

10

Dimensions and weight

Width

317 mm

Depth

328 mm

Operating Conditions

Operating Temperature

0..60 °C

Standards and Certifications

Certifications

CE, FCC Class A

Dimensions

Net Weight

0.8 kg

Gross Weight

0.8 kg

Backplane

Form Factor

PICMG 1.3 Passive Backplane

Extension Slots

Total

13

PCI Express x16

1

PCI Express x4

1

PICMG

1

PCI

10

Dimensions and weight

Width

317 mm

Depth

328 mm

Operating Conditions

Operating Temperature

0..60 °C

Standards and Certifications

Certifications

CE, FCC Class A

Dimensions

Net Weight

0.8 kg

Gross Weight

0.8 kg
