iWSN-1310-160-ME
ICP DAS
SKU: 09103400
iWSN Current Sensing Module with 3-ch CT Input and 1-ch Thermistor Input (RoHS) (Included 100A CT x3)
Price on request
Available
Available
Construction
Construction Chassis
Plastic Chassis
Mounting Configuration
Wall, Magnetic mount
RF Interface
Frequency
433 MHz
AC Power Measurement
Frequency
50/60Hz
Input Voltage
10...500V AC
Input Current
100А
CT Type
Split-core CT
Power Parameter Measurement
True RMS current (Irms)
Sensors
Measuring Range
0...+80 °С
Accuracy (+/-)
2 °C
Operating Conditions
Operating Temperature
0..45 °C
Dimensions and weight
Width
85 mm
Depth
25 mm
Height
152 mm
Standards and Certifications
EMS
IEC 61000-4-2, IEC 61000-4-4
Dimensions
Net Weight
0.2 kg
Gross Weight
0.35 kg
