iWSN-121A-240-ME
ICP DAS
SKU: 09103200
iWSN Current Sensing Module with 2-ch CT Input, 1-ch Thermistor Input and 1-ch DI (RoHS) (Included 200A CT x2)
Price on request
Available
Available
Construction
Construction Chassis
Plastic Chassis
Mounting Configuration
Wall, Magnetic mount
RF Interface
Frequency
433 MHz
AC Power Measurement
Frequency
50/60Hz
Input Voltage
10...500V AC
Input Current
200А
CT Type
Split-core CT
Power Parameter Measurement
True RMS current (Irms)
Sensors
Measuring Range
0...+80 °С
Accuracy (+/-)
2 °C
Digital Output
Total channels of digital output
1
Type
Signal Relay
Operating Conditions
Operating Temperature
0..45 °C
Dimensions and weight
Width
85 mm
Depth
25 mm
Height
152 mm
Standards and Certifications
EMS
IEC 61000-4-2, IEC 61000-4-4
Dimensions
Net Weight
0.2 kg
Gross Weight
0.35 kg
