IPPD-2100P-C

IPPD-2100P-C

NEXCOM
SKU: 57302400
21.5" IP66 Heavy Industrial 16:9 WXGA Zero Bezel Flush Touch Monitor, 300 nits, Projected Capacitive Touch, VGA, DVI-D, DisplayPort, 12...+24V DC-In
Price on request
Available on order
Available on order
Construction
Construction Chassis
Metal Chassis
Mounting Configuration
Desktop, Panel, Wall, Wall VESA 100
Protection Level of Front Side (Panel)
IP66
Material Front Side (Panel)
Aluminum
Display
Display Type
LCD TFT
Diagonal
21.5 "
Maximum resolution
1920x1080 Dots
Aspect Ratio
16:9
Brightness
300 Cd/m2
Contrast Ratio
5000~1
Input Interface
DisplayPort, VGA, DVI-D
Touch Screen
Touch Screen Type
Capacitive
Interface
USB
LED / Controls
LED
Power LED
Controls
On/Off
Connectors
Connectors
DVI-D, DB15 VGA, 1xUSB, Display Port, DC input (terminal block)
System Power Input
Input Voltage DC
12..24 V
Power Supply
Supported Types of Power Supply
External power adapter AC/DC
Operating Conditions
Operating Temperature
-10..60 °C
Humidity
10-90%
Vibration
IEC 68 2-64, 2Grms @ sine, 5~500Hz, 1hr/axis (operating), 2.2Grms @ random condition, 5~500Hz, 0.5hr/axis (non-operating)
Shock
IEC 68 2-27, HDD: 20G@wall mount, half sine, 11ms
Temperature (Storage)
-20~+70
Humidity (Storage)
10~95%
Dimensions and weight
Width
562.4 mm
Height
382.4 mm
Depth
50.85 mm
Standards and Certifications
Certifications
CE, FCC Class B
Dimensions
Net Weight
7.87 kg
Gross Weight
9 kg
