DSCP81-01

DSCP81-01

Dataforth
SKU: 02718700
DIN Rail, Config. Voltage Transmitter, 24-60VAC/DC, DIN Mount, Input -1000...1000 VDC and -100...100 mA, Output -10...10V and -20...20 mA
Price on request
Available
Available

Construction
Construction Chassis
Plastic Chassis
Mounting Configuration
DIN-Rail mount
Analog Input
Total channels of analog input
1
Current range
-100...+100 мА
Voltage range
+/-100 V, +/-1000 V
Analog Output
Channels of analog input
1
Current range
+/-20 mA
Voltage range
+/-10 V
Connectors
Connectors
Screw Terminal
System Power Input
Input Voltage DC
24..60 V
Dimensions and weight
Width
18 mm
Depth
114 mm
Height
63 mm
Operating Conditions
Operating Temperature
-25..55 °C
Standards and Certifications
Certifications
CE, EN 50081-2, EN 50082-2
Safety
UL
Dimensions
Net Weight
0.1 kg
Gross Weight
0.2 kg
