The SICOM3000A-LITE is a compact and rugged Layer 2 managed industrial Ethernet switch designed to meet the demanding requirements of utility substations, transportation systems, and industrial communication networks. With its modular design and comprehensive feature set, it offers a reliable and scalable networking solution for mission-critical applications.
Key Features
- Modular Design: The SICOM3000A-LITE supports various port configurations, including 8 Fast Ethernet ports and 2 Gigabit SFP ports, providing flexibility for future expansion.
- Redundancy Protocols: The switch supports various redundancy protocols including DT-Ring (recovery time < 50ms), DRP/DHP (recovery time < 20ms), STP/RSTP/MSTP, ensuring network reliability.
- Industrial Protocols: It supports EtherNet/IP and Modbus/TCP protocols, making it suitable for industrial automation applications.
- Network Security: The SICOM3000A-LITE offers advanced security features such as HTTPS/SSL, SSH, TACACS+, IEEE802.1X, RADIUS, User Classification, and MAC address binding with switch ports.
- Management & Monitoring: The switch supports multiple management interfaces including Console, Telnet, and Web (HTTP/HTTPS), and is compatible with SNMPv1/v2c/v3 for centralized management.
Expandable Modules
To meet diverse application needs, the SICOM3000A-LITE supports a range of optional modules:
- Time Synchronization Modules: HSR/PRP, TimeServer, GPS, IRIG-B, and TMS-trigger modules.
- Serial Communication: Serial server module supporting up to 24 RS232/422/485 ports.
- LED Module: For enhanced status indication and monitoring.
Compliance & Certifications
The SICOM3000A-LITE complies with industry standards including IEC61850-3 and IEEE1613, ensuring its suitability for harsh industrial environments.
