Axiomtek expands its panel PC lineup and announces three new models with different display sizes — 10.1”, 12.1”, and 15.6”. Built on the modern, energy-efficient Intel N150 processor, these systems are designed for a wide range of automation, equipment control, and data visualization applications in harsh operating environments.
All models in the series feature projected capacitive touchscreens, an IP65-rated front panel, IP30 enclosure protection, a wide 9–36 V DC input voltage range, and a rich set of interfaces. These include dual 2.5GbE Ethernet ports, USB ports of various generations, serial COM ports, and modern M.2 storage interfaces. This makes the entire lineup a versatile solution for HMI systems, industrial automation, process visualization, and industrial IoT projects.
The main differences between the models lie in the screen size and, consequently, their intended use cases. The GOT110A-TWL-WCD is the most compact model in the series and is equipped with a 10.1-inch display, making it suitable for space-constrained environments such as individual machines, local control panels, or transportation and logistics systems.
The GOT112A-TWL-WCD occupies a middle position in the lineup: its 12.1-inch display with good brightness provides more comfortable data visualization, while support for a 2.5-inch storage device expands storage options, making it well suited for operator panels and control rooms.
The flagship GOT115A-TWL-WCD comes with with a large 15.6-inch display and is designed for applications that require simultaneous visualization of large amounts of information—for example, operator workstations, production line monitoring systems, or centralized control centers. Thus, while maintaining a common architecture and feature set, the GOT-TWL-WCD series allows users to choose the optimal form factor to meet specific project requirements.
Key Technical Specifications:
|
Parameter |
|||
|
Display |
10.1″ WXGA |
12.1″ WXGA |
15.6″ WXGA |
|
Resolution |
1280x800 |
1280x800 |
1366х768 |
|
Brightness |
350 cd/m2 |
400 cd/m2 |
400 cd/m2 |
|
CPU |
Intel N150 |
Intel N150 |
Intel N150 |
|
RAM (standard) |
8 GB |
8 GB |
8 GB |
|
Storage |
M.2 + mSATA |
M.2 + mSATA + 2.5″ SATA |
M.2 + mSATA + 2.5″ SATA |
|
Ethernet |
2 × 2.5 GbE |
2 × 2.5 GbE |
2 × 2.5 GbE |
|
USB |
2 × USB 3.2 Gen2 2 × USB 2.0 1 x USB-C |
2 × USB 3.2 Gen2 2 × USB 2.0 1 x USB-C |
2 × USB 3.2 Gen2 2 × USB 2.0 1 x USB-C |
|
COM |
1 x RS-232/422/485 1 x RS-232 |
1 x RS-232/422/485 1 x RS-232 |
1 x RS-232/422/485 1 x RS-232 |
|
Power requirements |
9…36V DC |
9…36V DC |
9…36V DC |
|
Front panel protection rating |
IP65 |
IP65 |
IP65 |
|
All sides protection rating |
IP30 |
IP30 |
IP30 |
|
Mounting type |
Panel, wall, VESA75 |
Panel, wall, VESA100 |
Panel, wall, VESA100 |
The new GOT-TWL-WCD series of industrial panel PCs from Axiomtek provides engineers and system integrators with a proven, scalable platform for a wide range of automation tasks. Whether a compact 10-inch solution is needed for a standalone machine or a large 15-inch panel for a control center, all models deliver high performance, reliability, and protection for operation in demanding industrial environments.
