W43IF7T-PCA3
Winmate
SKU: 09169400
43" PanelPC, P-Cap Touch, Intel Core i5-9500TE 2.2GHz, 4GB DDR4, 128GB SSD, HDMI, DP, 2xGbE LAN, 1xCOM, 4xUSB 3.0, IP65 Front
Price on request
Available
Available
Construction
Construction Chassis
Metal Chassis
Mounting Configuration
Yoke mounting, VESA 200
Protection Level of Front Side (Panel)
IP65
Type
Fan
Display
Display Type
LCD TFT
Diagonal
43 "
Maximum resolution
1920x1080 Dots
Aspect Ratio
16:9
Brightness
400 Cd/m2
Contrast Ratio
3000~1
Input Interface
DisplayPort, HDMI
Touch Screen
Touch Screen Type
Capacitive
CPU
СPU Generation/Family
Coffee Lake Refresh
Processor Installed
Intel Core i5-9500TE
Socket
LGA1151
Max CPU frequency
2.2 GHz
Chipset
Chipset
Intel B360
Memory
Socket Type
2xSODIMM
Default on Board Memory
4 GB
Maximum Memory
64 GB
Assembly
Removable
Graphic
Graphic Controller
Integrated in CPU
Ethernet
Total Ethernet
2
10/100/1000 Mbit/s
2
Interfaces
COM Total
1
RS-232/422/485
1
USB Total
4
Drive interfaces
RAID Levels
1
M.2
1
Storage Cage
Number Of Cage External
2
2.5" Cage Intenal
2
Extension Slots
Total
2
M.2
2
LED / Controls
LED
1xHDD LED, Power LED
Controls
On/Off, 1xReset
Connectors
Connectors
DB9, HDMI, 2xRJ45 Ethernet, Mic In, Line Out, DC Input, Display Port
System Power Input
Input Voltage DC
24..24 V
Power Supply
Type of Power Supply
External power adapter AC/DC
Software
Operating System Compatibility
Ubuntu, Windows 10, Windows 11
Dimensions and weight
Width
1028.8 mm
Height
617 mm
Depth
62.8 mm
Operating Conditions
Operating Temperature
0..50 °C
Standards and Certifications
Certifications
CE, FCC
Dimensions
Net Weight
33 kg
Gross Weight
36 kg
