VPort P16-1MP-M12-IR-CAM80-CT

VPort P16-1MP-M12-IR-CAM80-CT

MOXA
SKU: 06710600
EN50155, HD image, fixed-dome IP camera, PoE, M12 connector, IR, MIC, 1DI, 8.0mm lens, -25 to 55C, coating
Price on request
Available on order
Available on order
Camera
Form Factor
Dome
Day&Night Mode
IR Cut Filter Remove
Video Analytics Functions
Motion Detection, Camera Tamper
Max Resolution Frame rate
30 fps
Ethernet
10/100 Mbit/s
1
Supported Protocols
Managment Protocols
SMTP, SNMPv1/v2c/v3, HTTP, Telnet, UDP, DNS, QoS, DHCP, NTP, DDNS, TFTP, IGMP, ARP, TCP, FTP, ICMP
Reservation protocols
RSTP
Security Protocols
HTTPS, SSH, IP Address Filtering, IEEE 802.1X Network Access Control, Password Protection
Digital Input
Total channels of digital input
1
Connectors
Connectors
4-pin M12 D-code female, 5-pin M12 male
System Power Input
Power over Ethernet (PoE)
PoE
Dimensions and weight
Width
125 mm
Depth
125 mm
Height
120.7 mm
Operating Conditions
Operating Temperature
-25..55 °C
Standards and Certifications
Certifications
CE, FCC
Corrosion resistance
ASTM B117
EMI
EN 55022 Class A, FCC Part 15
EMS
EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 61000-4-11
Freefall
IEC 60068-2-32
Rolling Stock
EN 50155, EN 50121-3-2
Safety
UL 60950-1
Vandal Resistance
EN 62262, IK10 level
Vibration And Shock
IEC 61373
Camera
Form Factor
Dome
Day&Night Mode
IR Cut Filter Remove
Video Analytics Functions
Motion Detection, Camera Tamper
Max Resolution Frame rate
30 fps
Ethernet
10/100 Mbit/s
1
Supported Protocols
Managment Protocols
SMTP, SNMPv1/v2c/v3, HTTP, Telnet, UDP, DNS, QoS, DHCP, NTP, DDNS, TFTP, IGMP, ARP, TCP, FTP, ICMP
Reservation protocols
RSTP
Security Protocols
HTTPS, SSH, IP Address Filtering, IEEE 802.1X Network Access Control, Password Protection
Digital Input
Total channels of digital input
1
Connectors
Connectors
4-pin M12 D-code female, 5-pin M12 male
System Power Input
Power over Ethernet (PoE)
PoE
Dimensions and weight
Width
125 mm
Depth
125 mm
Height
120.7 mm
Operating Conditions
Operating Temperature
-25..55 °C
Standards and Certifications
Certifications
CE, FCC
Corrosion resistance
ASTM B117
EMI
EN 55022 Class A, FCC Part 15
EMS
EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 61000-4-11
Freefall
IEC 60068-2-32
Rolling Stock
EN 50155, EN 50121-3-2
Safety
UL 60950-1
Vandal Resistance
EN 62262, IK10 level
Vibration And Shock
IEC 61373
Camera
Form Factor
Dome
Day&Night Mode
IR Cut Filter Remove
Video Analytics Functions
Motion Detection, Camera Tamper
Max Resolution Frame rate
30 fps
Ethernet
10/100 Mbit/s
1
Supported Protocols
Managment Protocols
SMTP, SNMPv1/v2c/v3, HTTP, Telnet, UDP, DNS, QoS, DHCP, NTP, DDNS, TFTP, IGMP, ARP, TCP, FTP, ICMP
Reservation protocols
RSTP
Security Protocols
HTTPS, SSH, IP Address Filtering, IEEE 802.1X Network Access Control, Password Protection
Digital Input
Total channels of digital input
1
Connectors
Connectors
4-pin M12 D-code female, 5-pin M12 male
System Power Input
Power over Ethernet (PoE)
PoE
Dimensions and weight
Width
125 mm
Depth
125 mm
Height
120.7 mm
Operating Conditions
Operating Temperature
-25..55 °C
Standards and Certifications
Certifications
CE, FCC
Corrosion resistance
ASTM B117
EMI
EN 55022 Class A, FCC Part 15
EMS
EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 61000-4-11
Freefall
IEC 60068-2-32
Rolling Stock
EN 50155, EN 50121-3-2
Safety
UL 60950-1
Vandal Resistance
EN 62262, IK10 level
Vibration And Shock
IEC 61373
Camera
Form Factor
Dome
Day&Night Mode
IR Cut Filter Remove
Video Analytics Functions
Motion Detection, Camera Tamper
Max Resolution Frame rate
30 fps
Ethernet
10/100 Mbit/s
1
Supported Protocols
Managment Protocols
SMTP, SNMPv1/v2c/v3, HTTP, Telnet, UDP, DNS, QoS, DHCP, NTP, DDNS, TFTP, IGMP, ARP, TCP, FTP, ICMP
Reservation protocols
RSTP
Security Protocols
HTTPS, SSH, IP Address Filtering, IEEE 802.1X Network Access Control, Password Protection
Digital Input
Total channels of digital input
1
Connectors
Connectors
4-pin M12 D-code female, 5-pin M12 male
System Power Input
Power over Ethernet (PoE)
PoE
Dimensions and weight
Width
125 mm
Depth
125 mm
Height
120.7 mm
Operating Conditions
Operating Temperature
-25..55 °C
Standards and Certifications
Certifications
CE, FCC
Corrosion resistance
ASTM B117
EMI
EN 55022 Class A, FCC Part 15
EMS
EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 61000-4-11
Freefall
IEC 60068-2-32
Rolling Stock
EN 50155, EN 50121-3-2
Safety
UL 60950-1
Vandal Resistance
EN 62262, IK10 level
Vibration And Shock
IEC 61373
Documentation
VPort P16-1MP-M12-IR Datasheet VPort P16-1MP-M12-IR User Manual VPort P16-1MP-M12-IR QIG VPort User's Manual
Documentation
VPort P16-1MP-M12-IR Datasheet VPort P16-1MP-M12-IR User Manual VPort P16-1MP-M12-IR QIG VPort User's Manual
Documentation
VPort P16-1MP-M12-IR Datasheet VPort P16-1MP-M12-IR User Manual VPort P16-1MP-M12-IR QIG VPort User's Manual
Documentation
VPort P16-1MP-M12-IR Datasheet VPort P16-1MP-M12-IR User Manual VPort P16-1MP-M12-IR QIG VPort User's Manual
MOXA VPort P16-1MP-M12-IR-CAM36 EN50155, HD image, fixed-dome IP camera, PoE, M12 connector, IR, MIC, 1DI, 3.6mm lens, -25 to 55C
MOXA VPort P16-1MP-M12-IR-CAM36-CT EN50155, HD image, fixed-dome IP camera, PoE, M12 connector, IR, MIC, 1DI, 3.6mm lens, -25 to 55C, coating
MOXA VPort P16-1MP-M12-IR-CAM80 EN50155, HD image, fixed-dome IP camera, PoE, M12 connector, IR, MIC, 1DI, 3.6mm lens, -25 to 55C, coating
MOXA VPort P16-1MP-M12-IR-CAM36-T EN50155, HD image, fixed-dome IP camera, PoE, M12 connector, IR, MIC, 1DI, 3.6mm lens, -40 to 70C
MOXA VPort P16-1MP-M12-IR-CAM80-T EN50155, HD image, fixed-dome IP camera, PoE, M12 connector, IR, MIC, 1DI, 8.0mm lens, -40 to 70C
