PDS-782

PDS-782

ICP DAS
SKU: 05145600
Programmable Device Server, 7xRS-232, 1xRS-485, RoHS
Price on request
Available
Available
Ethernet
10/100 Mbit/s
1
Interfaces
COM Total
8
RS-232
7
RS-485
1
Connectors
Connectors
Screw Terminal
System Power Input
Input Voltage DC
10..30 V
Operating Conditions
Operating Temperature
-25..75 °C
Construction
Construction Chassis
Plastic Chassis
Mounting Configuration
DIN-Rail mount, Wall
Dimensions and weight
Width
72 mm
Depth
35 mm
Height
123 mm
Dimensions
Net Weight
0.2 kg
Gross Weight
0.35 kg
Ethernet
10/100 Mbit/s
1
Interfaces
COM Total
8
RS-232
7
RS-485
1
Connectors
Connectors
Screw Terminal
System Power Input
Input Voltage DC
10..30 V
Operating Conditions
Operating Temperature
-25..75 °C
Construction
Construction Chassis
Plastic Chassis
Mounting Configuration
DIN-Rail mount, Wall
Dimensions and weight
Width
72 mm
Depth
35 mm
Height
123 mm
Dimensions
Net Weight
0.2 kg
Gross Weight
0.35 kg
Ethernet
10/100 Mbit/s
1
Interfaces
COM Total
8
RS-232
7
RS-485
1
Connectors
Connectors
Screw Terminal
System Power Input
Input Voltage DC
10..30 V
Operating Conditions
Operating Temperature
-25..75 °C
Construction
Construction Chassis
Plastic Chassis
Mounting Configuration
DIN-Rail mount, Wall
Dimensions and weight
Width
72 mm
Depth
35 mm
Height
123 mm
Dimensions
Net Weight
0.2 kg
Gross Weight
0.35 kg
Ethernet
10/100 Mbit/s
1
Interfaces
COM Total
8
RS-232
7
RS-485
1
Connectors
Connectors
Screw Terminal
System Power Input
Input Voltage DC
10..30 V
Operating Conditions
Operating Temperature
-25..75 °C
Construction
Construction Chassis
Plastic Chassis
Mounting Configuration
DIN-Rail mount, Wall
Dimensions and weight
Width
72 mm
Depth
35 mm
Height
123 mm
Dimensions
Net Weight
0.2 kg
Gross Weight
0.35 kg
Documentation
datasheet datasheet-pds-762-g-cr PDS-7xx Usermanual
Software
eSearch Utility VxComm Utility
Documentation
datasheet datasheet-pds-762-g-cr PDS-7xx Usermanual
Software
eSearch Utility VxComm Utility
Documentation
datasheet datasheet-pds-762-g-cr PDS-7xx Usermanual
Software
eSearch Utility VxComm Utility
Documentation
datasheet datasheet-pds-762-g-cr PDS-7xx Usermanual
Software
eSearch Utility VxComm Utility
