MX500B-QAA-A1

Accelerator Card with 8x Intel Movidius VPU Myriad-X 2485, 4 TOPS, CPUs 2x LEON 4 cores, 4Gb per VPU LPDDR4(Total 32GB), PCI Express x4 3.0, Ubuntu 16.04, Windows 10 Enterprise, M/JPEG 4K at 60Hz encoder, H.264/H.265 4K at 30Hz encoder

FPGA Machine Vision Solution Kit, 1xHDMI 1.4, 1xRJ45 GbE LAN, 4xUSB 3.1, 5xGPIO, 1xUART, 2xCANbus, 1xI2C, 1xMicroSD, 1xUSB Type-C, 12VDC-in, -40...+75C

FPGA Machine Vision Solution Kit, 1xHDMI 1.4, 1xRJ45 GbE LAN, 4xUSB 3.1, 5xGPIO, 1xUART, 2xCANbus, 1xI2C, 1xMicroSD, 1xUSB Type-C, 12VDC-in, 0...+70C

MXM GPU Module, NVIDIA RTX PRO 4000 Blackwell, 1545/2197MHz Base/Boost, CUDA 7680-Cores, Tensor 240-Cores, RT 60-Cores, 16GB GDDR7 VRAM (256-bit), 7680x4320 Max. Res., Up to 4xDP, PCIe 4.0 x16, MXM 3.1 Type-B, TDP 115W

MXM GPU Module, NVIDIA RTX PRO 4000 Blackwell, 975/1695MHz Base/Boost, CUDA 7680-Cores, Tensor 240-Cores, RT 60-Cores, 16GB GDDR7 VRAM (256-bit), 7680x4320 Max. Res., Up to 4xDP, PCIe 4.0 x16, MXM 3.1 Type-B, TDP 80W

MXM GPU Module, NVIDIA RTX PRO 500 Blackwell, 2160/2565MHz Base/Boost, CUDA 1792-Cores, Tensor 56-Cores, RT 14-Cores, 6GB GDDR7 VRAM (96-bit), 7680x4320 Max. Res., Up to 3xDP, PCIe 4.0 x8, MXM 3.1 Type-A, TDP 60W

MXM GPU Module, NVIDIA RTX PRO 5000 Blackwell, 1402/1935MHz Base/Boost, CUDA 10496-Cores, Tensor 320-Cores, RT 80-Cores, 24GB GDDR7 VRAM (256-bit), 7680x4320 Max. Res., Up to 4xDP, PCIe 4.0 x16, MXM 3.1 Type-B, TDP 115W

MXM GPU Module, NVIDIA RTX PRO 5000 Blackwell, 1095/1740MHz Base/Boost, CUDA 10496-Cores, Tensor 320-Cores, RT 80-Cores, 24GB GDDR7 VRAM (256-bit), 7680x4320 Max. Res., Up to 4xDP, PCIe 4.0 x16, MXM 3.1 Type-B, TDP 95W

MXM GPU Module, NVIDIA RTX PRO 2000 Blackwell, 1522/2070MHz Base/Boost, CUDA 3328-Cores, Tensor 104-Cores, RT 26-Cores, 8GB GDDR7 VRAM (128-bit), 7680x4320 Max. Res., Up to 3xDP, PCIe 4.0 x8, MXM 3.1 Type-A, TDP 60W

MXM GPU Module, NVIDIA RTX PRO 2000 Blackwell, 952/1657MHz Base/Boost, CUDA 3328-Cores, Tensor 104-Cores, RT 26-Cores, 8GB GDDR7 VRAM (128-bit), 7680x4320 Max. Res., Up to 3xDP, PCIe 4.0 x8, MXM 3.1 Type-A, TDP 45W

PCIe Highest Performance Accelerator Card with 5 x Coral edge TPU, PCI Express Gen2 x4, -20~55 Operating temperature

Computing Accelerator Card supports Two Intel Celeron 3865U with , 8GB (2GB x4) DDR4, PCIe x4 interface, QTS-Lite, and RoHS

Computing Accelerator Card supports Two Intel Core i7-7567U with Intel 600P 1TB (512GB x2) SSD, 32GB (8GB x4) DDR4, PCIe x4 interface, QTS-Lite, and RoHS

Computing Accelerator Card supports Two Intel Core i5-7267U with Intel 600P 1TB (512GB x2) SSD, 32GB (8GB x4) DDR4, PCIe x4 interface, QTS-Lite, and RoHS
