The Nexcom IPPC (Industrial Panel PC) series is an all-in-one rugged panel computer with a built-in display and touch interface, designed for heavy-duty applications. The IPPC lineup integrates a high-quality TFT LCD (with LED backlight) and projected-capacitive (PCAP) touchscreen into an aluminum chassis with a NEMA4/IP66-rated front bezel.
Nexcom IPPCs deliver integrated touchscreen displays and Intel processors in an ultra-rugged package suitable for factory floors and outdoor operation. Nexcom’s IPPC Series emphasizes durability and integration. The units use sturdy metal housings – typically an aluminum chassis and front bezel – to withstand shock, vibration and moisture. All models are fanless (passively cooled) for reliability, with DC power inputs typically in the 12–30V or 24V range. The front panels are designed for IP66/IP69K ingress protection, making them wash-down capable in food, pharmaceutical or outdoor environments.
Each IPPC uses a capacitive (PCAP) multi-touch screen – often 10-point – flush-mount and with high brightness (250–450 cd/m² depending on model) to ensure visibility in industrial lighting.
IPPC units support a variety of Intel CPUs. Some models use power-efficient Celeron processors (e.g. the Celeron J1900/J3455 or Intel N-series up to 3.6 GHz), while higher-end “C11” variants use socketed 10th-generation Core CPUs (i3/i5/i7/i9, Pentium or Celeron) on an Intel H420E chipset. This range lets customers select the processing power needed for tasks from simple HMIs to edge computing or machine vision.
Typical I/O includes dual Gigabit Ethernet, multiple USB ports (usually at least two USB 3.0 and two USB 2.0), serial COM ports (often two RS-232/422/485), and video outputs (DisplayPort or VGA) for dual-display setups. Internally, most models provide expansion such as one mini-PCIe slot, one or two M.2 slots (for Wi-Fi/SSD), plus 2.5″ drive bays or CFast slots for storage. All connectors (power, LAN, USB, COM) are conveniently grouped on the back or side.
Thanks to these features, Nexcom IPPCs excel as industrial HMIs, machine controllers, and edge computing nodes. They are commonly used for process automation panels, operator touchscreens, machine vision interfaces and IoT gateways. For example, IPPC 15.6″/18.5″/21.5″ are aimed for “industrial and factory automation, monitoring systems, edge servers, machine vision, and IIoT” applications. Their wide-input voltage, IP66 front, and fanless build also suit mobile or vehicle applications.
In summary, the IPPC series combines ruggedized design, full-touch displays, and rich I/O in one package – making it a versatile solution for harsh-environment control panels and HMI terminals.
Nexcom IPPC Series
Nexcom’s current IPPC models span screen sizes from 10.1″ to 23.8″, all with PCAP multi-touch. For example, 10.1″ and 15.6″ models (IPPC-1050P, IPPC-1640P-C, IPPC-1650P, IPPC-1660-A11) have WXGA or 1366x768 resolution. 18.5″ models (IPPC-1850P) and 21.5″ models (IPPC-2111-C11, IPPC-2140P-C, IPPC-2150P, IPPC-2160-A11) come in WXGA or Full HD. The largest 23.8″ screens (IPPC-2411-C11, IPPC-2460-A11) are Full HD. All these displays use projected-capacitive (P-Cap) touchscreens flush to the bezel.
Across the series, performance of systems differs from low-power Celeron/N-series chips up to 10th-gen Core processors (socket LGA1200). For example, the IPPC-1611-C11 and IPPC-2111-C11 support 10th Gen Intel Core i3/i5/i7/i9 (and equivalent Pentium/Celeron) CPUs on an H420E chipset. More power-efficient models like the IPPC-2140P-C use the Celeron J1900 (Apollo Lake) processor. Memory is DDR4 or DDR3L (up to 32 GB), and most models offer options for extra COM ports, DIO or audio. Power inputs vary (commonly 12–30 VDC or 24 VDC) with optional wide-range voltage supplies for vehicle use. Common I/O across the line includes dual Gigabit LAN, multiple USB 3.0/2.0 ports, serial COM, DisplayPort and sometimes VGA. Many models also include expansion: e.g. mini-PCIe, M.2 slots, 2.5″ drive bays or CFast slots for storage. All models are fanless and rated IP66 front panel.
In short, the IPPC series lets engineers pick the screen size, processing power, and I/O mix needed for a panel-PC project without sacrificing ruggedness.
Featured Products
- Nexcom – IPPC-1050P
10.1″ WXGA LED Panel PC, 1280x800, 300 cd/m², Capacitive Touch Screen, Intel Celeron J3455 1.5 GHz CPU, 4 GB DDR3L, 2xDP, 2xGbE LAN, 3xCOM, 2xUSB3.0, 2xUSB2.0, mPCIe, M.2 2242, 1x2.5″ SATA HDD Bay, 24VDC-in, IP66 front. - Nexcom – IPPC-1611-C11
15.6″ WXGA LED Fanless Panel PC, 1366x768, PCAP Touch, supports 10th Gen Intel Core i9/i7/i5/i3/Pentium/Celeron CPUs, DDR4 up to 32 GB, DP++, 2xGbE LAN, 2xCOM, 2xUSB 3.1, M.2 (B-key & 2242), mini-PCIe, 24VDC-in. - Nexcom – IPPC-1640P-C
15.6″ WXGA LED Fanless Panel PC, 1366x768, Capacitive Touch Screen, Intel Celeron J1900 2.42 GHz CPU, 4 GB DDR3L, 1x2.5″ SATA HDD Bay, CFast, 2xCOM, 2xUSB, 2xGbE LAN, 2xmini-PCIe, VGA, Audio (optional), 12–30VDC-in. - Nexcom – IPPC-1650P
15.6″ Panel PC, IP66 Front, 1366x768 HD LED, 400 cd/m², PCAP Touch, Intel Celeron J3455 1.5 GHz CPU, 4 GB DDR3L, 2xDP, 2xGbE LAN, 3xCOM, 2xUSB3.0, 2xUSB2.0, mini-PCIe, 1xM.2 2242, 1x2.5″ HDD Bay, 24VDC-in. - Nexcom – IPPC-1660-A11
15.6″ Fanless Panel PC, IP66 Front, 1366x768 HD, 400 cd/m², PCAP Touch, Intel N97 3.6 GHz CPU, 8 GB DDR5 (up to 16 GB), 1xDP, 2xGbE LAN, 2xCOM, 2xUSB 3.2, 1xUSB 3.2 Type-C (DP Alt Mode), optional 2xCOM/DIO/Audio, 1xmini-PCIe, 2xM.2 Key-B, PCIe x1, 24VDC-in. - Nexcom – IPPC-1850P
18.5″ Panel PC, IP66 Front, 1366x768 HD LED, 400 cd/m², Capacitive Touch Screen, Intel Celeron J3455 1.5 GHz CPU, 4 GB DDR3L, 2xDP, 2xGbE LAN, 3xCOM, 2xUSB3.0, 2xUSB2.0, mini-PCIe, M.2 2242, 1x2.5″ SATA Bay, 24VDC-in. - Nexcom – IPPC-2111-C11
21.5″ Fanless Panel PC, 1920x1080 FHD, PCAP Touch, 10th Gen Intel Core i3/i5/i7/i9/Celeron/Pentium CPUs, H420E Chipset, up to 32 GB DDR4, DP output, 2xGbE LAN, 2xCOM, 2xUSB 3.1, 1x2.5″ Drive Bay, 1xPCIe x4, 1xmini-PCIe, 2xM.2 Key-B, SIM slot, 24VDC-in. - Nexcom – IPPC-2140P-C
21.5″ WXGA LED Fanless Panel PC, 1920x1080 (Full HD), PCAP Touch, Intel Celeron J1900 2.42 GHz CPU, 4 GB DDR3L, 1x2.5″ SATA HDD Bay, CFast, 2xCOM, 3xUSB, 2xGbE LAN, 2xmini-PCIe, VGA, 12–30VDC-in. - Nexcom – IPPC-2150P
21.5″ Panel PC, IP66 Front, 1920x1080 FHD, 250 cd/m², PCAP Touch, Intel Celeron J3455 1.5 GHz CPU, 4 GB DDR3L, 2xDP, 2xGbE LAN, 3xCOM, 2xUSB3.0, 2xUSB2.0, mini-PCIe, 1xM.2 2242, 1x2.5″ HDD Bay, 24VDC-in. - Nexcom – IPPC-2160-A11
21.5″ Fanless Panel PC, IP66 Front, 1920x1080 FHD, 250 cd/m², PCAP Touch, Intel N97 3.6 GHz CPU, 8 GB DDR5 (up to 16 GB), 1xDP, 2xGbE LAN, 2xCOM, 2xUSB 3.2, 1xUSB 3.2 Type-C (DP Alt), optional 2xCOM/DIO/Audio, 1xmini-PCIe, 2xM.2 Key-B, PCIe x1, 24VDC-in. - Nexcom – IPPC-2411-C11
23.8″ Fanless Panel PC, 1920x1080 FHD, PCAP Touch, 10th Gen Intel Core i3/i5/i7/i9/Celeron/Pentium CPUs, H420E Chipset, up to 32 GB DDR4, DP output, 2xGbE LAN, 2xCOM, 2xUSB 3.1, 1x2.5″ Drive Bay, 1xPCIe x4, 1xmini-PCIe, 2xM.2 Key-B, SIM slot, 24VDC-in, 0–50 °C. - Nexcom – IPPC-2460-A11
23.8″ Fanless Panel PC, IP66 Front, 1920x1080 FHD, 450 cd/m², PCAP Touch, Intel N97 3.6 GHz CPU, 8 GB DDR5 (up to 16 GB), 1xDP, 2xGbE LAN, 2xCOM, 2xUSB 3.2, 1xUSB 3.2 Type-C (DP Alt), optional 2xCOM/DIO/Audio, 1xmini-PCIe, 2xM.2 Key-B, PCIe x1, 24VDC-in.
The Nexcom IPPC series offers a robust, highly integrated panel PC solution for industrial control and HMI applications. These units combine full-featured Intel-based computing with a sealed touchscreen display, all in a fanless, vibration-resistant enclosure. With screen sizes from 10.1″ to 23.8″ and options from Celeron to Core i9, they cover a broad spectrum of performance needs. Their designs (e.g. IP66 front panels, aluminum chassis, wide DC input) ensure reliability in harsh factory or outdoor settings. For system integrators and end-users, this means easier deployment of SCADA panels, machine interfaces, IIoT gateways and other automation terminals.
In short, Nexcom’s IPPC solutions provide an industrial PC/HMI platform – rugged, fanless and rich in I/O – ideally suited to modern automation challenges.
