NEXCOM’s Fanless Edge Computing System (Neu-X Series) is designed to meet the rigorous demands of modern edge computing applications. With its fanless architecture, industrial-grade reliability, and scalable performance, the Neu-X Series supports solutions ranging from intelligent kiosks to smart city deployments. Divided into two main categories — Neu-X Core and Neu-X Atom, the product line enables system integrators to match computing power and I/O capabilities with the specific requirements of edge environments.
Neu-X Computing System provides a modular and scalable platform for various edge computing applications. From high-performance models with Intel® Core™ processors to energy-efficient units, these systems deliver robust performance in mission-critical environments.
Their adaptability, rich I/O, and industrial-grade construction make them an ideal choice for integrators seeking reliable hardware for smart cities, transportation hubs, industrial control, or interactive kiosks. Available through IPC2U, the Neu-X product family empowers next-generation edge intelligence with the stability and endurance demanded by today's infrastructure.
Applications and System Advantages
These systems are purpose-built for applications in digital signage, intelligent transportation, industrial automation, and retail analytics. The Neu-X Series stands out due to its passive cooling, compact form factor, rich connectivity, and robust expansion options. They’re ideal for deployment in space-constrained or dust-prone environments, where fanless operation significantly reduces maintenance while improving longevity and stability.
Further advantages include wide-range DC power input, multiple LAN ports with 2.5G support, COM ports for legacy device interfacing, and high-speed NVMe storage. The availability of Intel Atom®, Celeron®, and Core™ processors makes it possible to choose between low-power efficiency and high-performance compute.
Neu-X Core
The Neu-X Core series delivers high-performance computing with Intel® Core™ processors and supports DDR4 or DDR5 memory configurations up to 64GB. These models are designed for tasks requiring intensive processing, graphics rendering, or AI-assisted edge analytics.
Key Features:
- Intel® 8th to 13th Gen Core™ processors
- Up to 64GB DDR4/DDR5 memory
- Dual 2.5G LAN, multiple USB and COM ports
- M.2 NVMe storage slots and expansion support
- Fanless aluminum chassis, 12V DC input
Featured products:
- Nexcom - Neu-X102-i3 Compact system with Alder Lake Intel® Core™ i3 processor and dual 2.5G LAN. Suitable for real-time data processing at the edge.
- Nexcom - Neu-X303 12th Gen Core™ solution with DDR5 support and rich expandability for high-throughput edge workloads.
- Nexcom - Neu-X303mini Smaller variant of Neu-X303 featuring the same powerful CPU options in a more compact enclosure.
- Nexcom - Neu-X304 Top-tier fanless system with support for Intel® Core™ i7/i9 processors and advanced I/O configuration. Designed for complex AI or multi-display deployments.
Fanless Embedded Server, Intel Core i3-N305 3.8GHz CPU, Up to 16GB DDR4 RAM, 2xHDMI, 2x2.5GbE LAN, 1xRS232/422/485, 4xUSB 3.2, MiniPCIe, 8-bit GPIO, 1xM.2 2242 M-Key, 12VDC-in with Power Adapter 60W
Fanless Edge Embedded Computing System, Intel 12th Gen Core i3/i5/i7 CPU, Up to 64GB DDR5 RAM, 1xM.2 2280 M-Key, 1xM.2 2230 E-Key, TPM 2.0, 1xHDMI, 1xDP, 2x2.5 GbE LAN, 1xRS232, 2xUSB 3.2 Type-C (support DP) , 4xUSB 3.2, 1xUSB 2.0, 12VDC-in
Fanless Edge Embedded System, Intel 12th Gen Core i3/i5/i7 LGA1700 CPU, up to 64GB DDR5 RAM, 1xM.2 2280 M-Key, 1xM.2 2230 E-Key, TPM 2.0, 1xHDMI, 1xDP, 2xGbE LAN, 1xRS232, 2xUSB 3.2 Type-C (support DP) , 4xUSB 3.2, 1xUSB 2.0, 12VDC-in
Fanless Edge Embedded System, LGA1700, Intel 12/13th Gen Core i3/i5/i7/i9 CPU, Up to 64GB DDR5 RAM, 3xHDMI/LVDS, 1xGbE LAN, 1x2.5GbE LAN, 2xCOM, 2xCOM headers, 4/3xUSB 3.2 , 4/5xUSB 2.0, 3xM.2, 8-bit GPIO, Audio, TPM 2.0, 12-24VDC-in
Neu-X Atom
The Neu-X Atom lineup focuses on low-power edge computing tasks. Equipped with Intel® Atom®, Celeron®, and Pentium® processors, these systems are optimized for cost-effective deployments where efficiency and stability matter most.
Key Features:
- Intel® Atom®/Celeron®/Pentium® CPUs
- Up to 2.5G LAN and COM ports
- 12V or wide-range DC input
- M.2 Key slots for wireless or SSD modules
- Ideal for kiosks, IoT gateways, and retail terminals
Featured products:
- Nexcom - Neu-X60 Compact and cost-effective Intel Atom®-based system with dual 2.5G LAN and M.2 expansion for connectivity.
- Nexcom - Neu-X104-N355 Fanless embedded computer using Intel® N355 processor with wide DC input and flexible I/O for automation or signage.
- Nexcom - Neu-X104-N150 Similar to the N355 version but with the N150 processor, offering more performance headroom while retaining energy efficiency.
- Nexcom - Neu-X102-N97 Energy-efficient design featuring the Intel® Processor N97 and advanced LAN/COM configuration, designed for compact smart terminals.
- Nexcom - Neu-X102-N50 Basic version of the Neu-X102 series with dual 2.5G LAN, making it ideal for light edge computing and digital signage.
Fanless Edge Computing System, Intel Alder Lake N50 3.4GHz CPU, Up to 16GB (4GB Inst.) DDR4 RAM, 1xHDMI, 1x2.5GbE LAN, 1xRS232/422/485, 2xUSB 3.2, 1xMiniPCIe Full-Size, 1xM.2 2242 M-Key (64GB SSD Inst.), 12VDC-in with Power Adapter 50W
Fanless Edge System, Intel Twin Lake N355 3.9GHz CPU, Up to 16GB DDR4 RAM, 2xHDMI, 2x2.5GbE LAN, 4xUSB 3.2, 1xCOM, 8-bit GPIO Int., 1xMiniPCIe Full-Size, 1xM.2 2242 Key-M (SATA), 12VDC-in with 60W Power Adapter
Fanless Edge System, Intel Twin Lake N150 3.6GHz CPU, Up to 16GB DDR4 RAM, 2xHDMI, 2x2.5GbE LAN, 4xUSB 3.2, 1xCOM, 8-bit GPIO Int., 1xMiniPCIe Full-Size, 1xM.2 2242 Key-M (SATA), 12VDC-in with 60W Power Adapter
Fanless Embedded Server, Intel Alder Lake N97 3.6GHz CPU, Up to 16GB DDR4 RAM, 2xHDMI, 2x2.5GbE LAN, 1xRS232/RS422/RS485, 4xUSB 3.2, MiniPCIe, 8-bit GPIO Int., 1xM.2 2242 M-Key, 12VDC-in with Power Adapter 60W
Fanless Embedded Server, Intel Alder Lake N50 3.4GHz CPU, Up to 16GB DDR4 RAM, 2xHDMI, 2x2.5GbE LAN, 1xRS232/RS422/RS485, 4xUSB 3.2, 1xMiniPCIe, 8-bit GPIO Int., 1xM.2 2242 M-Key, 12VDC-in with Power Adapter 60W
