Vehicle Telematics Computer with Intel 9th Gen i7-9700TE 1.8 GHz CPU, 8GB DDR4, VGA, HDMI, 4x1000 PoE 802.3af/at, 2x1000 Mbps LAN, 2xRS232, 1xRS232/422/485, 2xUSB, 2x2.5" SATA Drive Bay, 2xmSATA, 3xMini-PCIe, 2xM.2 , CANBus, 9-36V DC-In, -30..60C
VTC-7252-7C4IP
NEXCOM
SKU: 57280400
Price on request
Available on order
Available on order
Construction
Construction Chassis
Rubber
Protection Level of Chassis
IP65
Type
Fanless
CPU
СPU Generation/Family
Coffee Lake Refresh
Processor Installed
Intel Core i7-9700TE
Max CPU frequency
3.8 GHz
Chipset
Chipset
Intel C246
Memory
Form-factor
DDR4
Socket Type
2xSODIMM
Default on Board Memory
8 GB
Maximum Memory
64 GB
Assembly
Removable
Graphic
Graphic Controller
Intel UHD Graphics 630
Ethernet
10/100/1000 Mbit/s
2
Interfaces
COM Total
3
RS-232
2
RS-232/422/485
1
USB Total
3
USB 2.0
1
USB v3.x
2
Industrial Interfaces
CAN Port
2
Drive interfaces
RAID Levels
1, 5, 10
mSATA
1
CFast Slots
1
Storage Cage
2.5" Cage Intenal
2
Extension Slots
M.2
2
Mini-PCIe/Mini Card
3
SIM Card slots
2, Micro-SIM
Antenna characteristics
Cellular interfaces
3G
Additional Functions
GPS
GPS
Watchdog timer type
Software
Connectors
Connectors
DB15 VGA, HDMI, 1xUSB, 3xM12, 2xSIM Card Slot, SMA Female, 5-pin M12 DC, CFast slot, 4xM12 PoE, 2xM12 LAN
System Power Input
Input Voltage DC
9..36 V
Software
Operating System Compatibility
Linux OS, Windows 10
Dimensions and weight
Width
256 mm
Height
66.5 mm
Depth
256.4 mm
Operating Conditions
Operating Temperature
-30..60 °C
Vibration
2g @ 5~500 Hz
Shock
20G, 11 м
Standards and Certifications
Certifications
CE, FCC Class A
MIL-STD-810
MIL-STD-810G Test Method 514.6 Vibration, MIL-STD-810G Test Method 516.6 Shock
Vehicle
E-Mark
Dimensions
Net Weight
4.5 kg
Gross Weight
6 kg
