VTC-1020-BQ

Name:

NEXCOM

Construction Chassis:

Metal Chassis with Aluminium Heatsink

Mounting Configuration:

Built-in, Wall

Processor Supported:

Intel Atom x5-E3930

Frequency:

1.8 GHz

Memory Type:

DDR3L

Default on Board Memory:

4 GB

Maximum Memory:

16 GB

Total Ethernet:

1

10/100/1000 Mbit/s:

1

COM Total:

2

RS-232:

2

USB Total:

2

USB 3.0:

2

SATA 3 Channels:

1

2.5" Drive Bays:

SATA 3

mSATA Support:

Yes

Number Of Cage External:

1

2.5" Cage Intenal:

1

Total:

2

Mini-PCIe/Mini Card:

2

Quantity of SIM Card:

1

GPS:

Yes

Type:

Fanless

Connectors:

DB9, DB15 VGA, HDMI, RJ45 Ethernet, 2xUSB, Mic In, Line Out

Input Voltage DC:

9 ... 36 V

Power Consumption:

15 W

Operating System Compatibility:

Linux OS, Windows 10

Width:

185 mm

Height:

50 mm

Depth:

120 mm

Temperature:

-40 ... 70 °C

Humidity:

10 ... 90 % (non-condensing)

Vibration:

2g @ 5~500 Hz

Certifications:

CE, FCC Class B

MIL-STD-810:

MIL-STD-810F Test Method 516.5 Crash Hazard, MIL-STD-810F Test Method 514.5 Highway Truck

Automotive:

e13 Mark
