PBSW-090T-8A-E8-4G

PBSW-090T-8A-E8-4G Industrial Panel PC with Intel Atom x5-E8000, 4GB DDR3L RAM, 9'' Touch Screen, 2x USB, 1x COM, GbE LAN The PBSW-090T-8A-E8-4G is a compact industrial panel PC for local automation and H2M applications. It combines a 9'' touch screen with an efficient Intel Atom x5-E800 processor and a selection of interfaces for direct control and integration of peripheral devices as well as possibilities for networking via WiFi and WWAN. The Intel Atom x5-E8000 CPU used in the PBSW-090T-8A-E8-4G is based on modern 14nm lithography and combines four computing cores with a clock frequency of 1.04 GHz and an extremely low power dissipation of only 5 Watt TDP. The main memory consists of a 4GB DDR3L Low Energy RAM and is soldered on the motherboard like the CPU. The Industrial Panel PC PBSW-090T-8A-E8-4G displays the data on a 9'' LCD TFT touch screen with resistive detection, which uses a resolution of 1024 x 600 pixels with an aspect ratio of 17:10. The native I/O of the compact industrial Panel PC includes Ethernet with 10/100/1000 Mbit/s, two USB 3.0 ports on the top side as well as Serial COM RS232 via DB-9. Typical applications of the Panel PC are the direct control and monitoring of processes and factory machines and the usage as compact IoT H2M terminals in different environments like smart factories or building automation.
