15" Fanless Panel PC, 1024x768, PCAP Touch, 400cd/m2, MediaTek Genio 350 SoC, 4GB LPDDR4x RAM, 64GB eMMC Flash, 1x100Mbit LAN, 2xUSB 2.0, 1xMicroUSB, 2xCOM, 6-bit DIO, CAN, MicroSD, Wi-Fi5/BT5/GPS, 9-36VDC-in, -20..70C, Android 13
IOT-150CA
Arbor
SKU: 80061200
Price on request
Available on order
Available on order
Construction
Construction Chassis
Metal Chassis
Mounting Configuration
Panel, Wall VESA 75
Type
Fanless
Display
Display Type
LCD TFT
Diagonal
15 "
Maximum resolution
1024x768 Dots
Aspect Ratio
4:3
Brightness
400 Cd/m2
Touch Screen
Touch Screen Type
Capacitive
CPU
Processor Installed
MediaTek MT8365 (Genio 350)
Socket
CPU onboard
Max CPU frequency
2 GHz
Chipset
Chipset
SoC
Memory
Form-factor
DDR4
Socket Type
Soldered
ECC
No
Default on Board Memory
4 GB
Assembly
Fixed on Board
Graphic
Graphic Controller
Integrated in CPU
Ethernet
Controller Type
Integrated with Chipset
Total Ethernet
1
10/100 Mbit/s
1
Wi-Fi
Wi-Fi Standard
802.11a/b/g/n/ac
Interfaces
COM Total
2
RS-232
1
RS-232/422/485
1
USB Total
3
USB 2.0
3
Digital Input-Output
Channels of DIO
6
Industrial Interfaces
CAN Port
1
Drive interfaces
SD Slots
1
Installed drive
Storage Form-Factor
eMMC
1st Storage Capacity
64 GB
Additional Functions
GPS
GPS, GLONASS
LED / Controls
Controls
On/Off
Connectors
Connectors
2xDB9, RJ45 Ethernet, 2xUSB, DC input (terminal block), 1xMicro USB
System Power Input
Input Voltage DC
9..36 V
Power Supply
Supported Types of Power Supply
External power adapter AC/DC
Software
Operating System Installed
Android
Dimensions and weight
Width
348.88 mm
Height
272.82 mm
Depth
47.5 mm
Operating Conditions
Operating Temperature
-20..70 °C
Humidity
10-95%
Dimensions
Net Weight
2.4 kg
Gross Weight
3 kg
Documentation
