RS-232 to RS-422/2xRS-485 Converter with RS-485 Automatic Data Direction Control, Isolation Protection
I-7520U
ICP DAS
SKU: 03136400
Price on request
Available on order
Available on order
Interfaces
COM Total
3
RS-232
1
RS-485
1
RS-422/485
1
Isolation of COM Ports
3 kV (RS-232)
System Power Input
Input Voltage DC
10..30 V
Operating Conditions
Operating Temperature
-25..75 °C
Construction
Mounting Configuration
DIN-Rail mount
Dimensions and weight
Width
72 mm
Depth
35 mm
Height
118 mm
Dimensions
Net Weight
0.22 kg
Gross Weight
0.25 kg
