4U Rackmount Processor-based Platform with support Intel Xeon E5-2600 v3/v4, up to 256 Gb DDR3 1600/1866/2133 MHz, 2x 2.5'' HDD, 8x 2.5''/3.5'' Hot-Swap HDD, 3x 5'' HDD, 2x GbE LAN, 4xUSB, 3xPCIe x16, 1x PCIe x8, power supply 1800 W
HPC-7483-S923
Advantech
SKU: 07975800
Price on request
Available on order
Available on order
Construction
Construction Chassis
Heavy-Duty Steel Chassis
Mounting Configuration
19" Rackmount
Height
4 U
Type
Fans
CPU
Socket
LGA 2011-R3
CPU Support Type
Xeon
Number of CPU
1
Chipset
Chipset
Intel C612
Memory
Form-factor
DDR4
ECC
Yes
Maximum Memory
256 GB
Graphic
Graphic Controller
Aspeed AST2400
Graphic Memory Size
0.06 GB
Interfaces
VGA
Ethernet
Controller Type
Intel i210-AT
Total Ethernet
1
10/100/1000 Mbit/s
1
Interfaces
COM Total
1
RS-232
1
USB Total
4
USB 2.0
2
USB v3.x
2
Storage Cage
2.5" Cage Intenal
2
3.5" Cage External
8
5.25" Cage Internal
3
Extension Slots
PCI Express x16
4
PCI Express x8
2
PCI Express x4
1
LED / Controls
LED
1xHDD LED, Power Fail, LAN LED
Additional Functions
Watchdog timer type
Software
Connectors
Connectors
DB15 VGA, PS/2 Keyboard/Mouse, RJ45 Ethernet, 4xUSB, Console Port RS-232 (RJ-45), RJ-45 (IPMI)
System Power Input
Input Voltage AC
100..240 V
Power Supply
Type of Power Supply
Redundant
Dimensions and weight
Width
482 mm
Height
177 mm
Depth
448 mm
Operating Conditions
Operating Temperature
0..35 °C
Vibration
1 Grms
Shock
10 G
Dimensions
Net Weight
5.4 kg
Gross Weight
6 kg
