2U Rackmount Processor-based Platform, support 2xIntel Xeon E5-2600, Intel C604, DDR3 1066/1333/1600 DIMM, 4xPCIe x8, 1xPCIe x8 riser card, 2xLAN, 4xNMC, 4x2.5" hot-swap SAS/SATA, 1xCFast, 2xUSB, 1xCOM, PSU (1+1)
FWA-6510-00E
Advantech
SKU: 06731900
Price on request
Available on order
Available on order
Construction
Construction Chassis
Metal Chassis
Mounting Configuration
19" Rackmount
Height
2 U
Type
Fans
CPU
CPU Support Type
Xeon
Number of CPU
2
Chipset
Chipset
Intel С604
Memory
Form-factor
DDR3
Socket Type
12xDIMM
ECC
Yes
Registred
Yes
Maximum Memory
384 GB
Graphic
Graphic Controller
Integrated in CPU
Ethernet
Controller Type
Intel 82574L 10/100/1000 Mbps
Total Ethernet
2
10/100/1000 Mbit/s
2
Interfaces
COM Total
1
RS-232
1
USB Total
2
USB 2.0
2
Drive interfaces
CFast Slots
1
Storage Cage
2.5" Cage External
4
Extension Slots
Total
1
PCI Express x8
1
LED / Controls
LED
Power LED
Controls
On/Off, Control Buttons
Connectors
Connectors
2xRJ45 Ethernet, 2xUSB, RJ45 (COM)
Power Supply
Type of Power Supply
Redundant
Output Power
720 W
Input Voltage AC
100..240 V
Dimensions and weight
Width
430 mm
Height
88 mm
Depth
558 mm
Operating Conditions
Operating Temperature
0..40 °C
Dimensions
Net Weight
18 kg
Gross Weight
20 kg
