EtherCAT three-channel incremental encoder counter
ECAT-2093
ICP DAS
SKU: 08347500
Price on request
Available on order
Available on order
Construction
Construction Chassis
Plastic Chassis
Mounting Configuration
DIN-Rail mount
Ethernet
10/100 Mbit/s
2
Supported Protocols
Industrial Protocols
EtherCAT slave
Digital Input
Number of channels
3
Signal Type
CW/CCW, Pulse/Dir, AB Phase
Counter capacity
32 Bit
Max frequency
4 kHz
Connectors
Connectors
Screw Terminal
System Power Input
Input Voltage DC
20..30 V
Dimensions and weight
Width
33 mm
Depth
90 mm
Height
110 mm
Operating Conditions
Operating Temperature
-25..70 °C
Standards and Certifications
EMS
IEC 61000-4-2, IEC 61000-4-4, IEC 61000-4-5
Dimensions
Net Weight
0.3 kg
Gross Weight
0.5 kg
Documentation
