EtherCAT single axis stepper motor controller/ driver
ECAT-2091S
ICP DAS
SKU: 66496500
Price on request
Available on order
Available on order
Construction
Construction Chassis
Metal Chassis
Mounting Configuration
DIN-Rail mount
Ethernet
10/100 Mbit/s
2
Supported Protocols
Industrial Protocols
EtherCAT slave
Digital Input
Total channels of digital input
2
Type
Wet contact
Level of Logic "0"
0~11 V
Level of Logic "1"
19~30 V
Sink/Source
Sink, Source
Isolation of Digital Input
3750 V
Number of channels
1
Max frequency
4 kHz
Digital Output
Total channels of digital output
1
Type
Open collector
Output voltage
5~30 V
Max. load current
100 mA
Channels
1
System Power Input
Input Voltage DC
20..30 V
Dimensions and weight
Width
33 mm
Depth
120 mm
Height
117 mm
Operating Conditions
Operating Temperature
-25..40 °C
Standards and Certifications
EMS
IEC 61000-4-2, IEC 61000-4-4, IEC 61000-4-5
Dimensions
Gross Weight
0.5 kg
