6-ch DI and 6-ch Relay 1 A @ 30 VDC, 0.5 A @ 120 VAC Modbus TCP Module, 10-30VDC-in
ADAM-6060-D
Advantech
SKU: 66479600
Price on request
Available on order
Available on order
Construction
Construction Chassis
Plastic Chassis
Mounting Configuration
DIN-Rail mount, Wall
Ethernet
10/100 Mbit/s
1
Additional Functions
Watchdog timer type
Hardware, Software
Supported Protocols
Industrial Protocols
Modbus TCP server
Digital Input
Total channels of digital input
6
Type
Dry contact, Wet contact
Level of Logic "0"
0~3 V
Level of Logic "1"
10~30 V
Sink/Source
Sink, Dry: Source
Counter
3KHz
Digital Output
Total channels of digital output
6
Type
Electromagnitic relay
Relay (Form A)
6
Contact rating of relay (Form A)
05A@120V AC, 1A@30V DC
Connectors
Connectors
Screw Terminal
System Power Input
Input Voltage DC
10..30 V
Dimensions and weight
Width
70 mm
Depth
27 mm
Height
122 mm
Operating Conditions
Operating Temperature
-40..70 °C
Dimensions
Net Weight
0.21 kg
Gross Weight
0.21 kg
