Industrial 8-port unmanaged IP67 Ethernet switch with PoE Includes M12D-4P-IP68 x 8, A-CAP-M12M x 8, M12A-5P-IP68 and A-CAP-M12F x 1
NS-208PSE-M12-IP67
ICP DAS
SKU: 06909900
Price on request
Available on order
Available on order
Ethernet
Total Ethernet
8
10/100 Mbit/s
8
Type 10/100 Mbit/s
8xM12
PoE 10/100 Mbit/s
8
Switch Properties
Managed
No
Switch Level
Layer 2
Supported Protocols
IEEE Standard
IEEE 802.3 for 10BaseT, IEEE 802.3u for 100BaseT(X) and 100BaseFX, IEEE 802.3x for Flow Control
System Power Input
Input Voltage DC
46..53 V
Construction
Construction Chassis
Plastic Chassis
Mounting Configuration
DIN-Rail mount
Protection Level of Chassis
IP67
Dimensions and weight
Width
190 mm
Depth
134 mm
Height
62 mm
Operating Conditions
Operating Temperature
-40..75 °C
Standards and Certifications
Certifications
CE, FCC
Dimensions
Gross Weight
0.6 kg
