VTC-1020

VTC-1020

NEXCOM
SKU: 07321700
Embedded server with Intel Atom processor x5-E3930 1.8GHz CPU, 4GB DDR3L SO-DIMM, VGA+HDMI, Gb LAN, 5xRS-232, 2xRS-485, 1xCAN, 2xUSB 3.0, 2xMini-PCIe, 9...36V DC input, 12VDC output
Price on request
Available
Available
Construction
Construction Chassis
Aluminium Chassis
Mounting Configuration
Embedded, Desktop, Wall
Type
Fanless
CPU
Processor Installed
Intel Atom x5-E3930
Max CPU frequency
1.8 GHz
Memory
Form-factor
DDR3L
Socket Type
1xSODIMM
Default on Board Memory
4 GB
Maximum Memory
8 GB
Assembly
Removable
Graphic
Graphic Controller
Integrated in CPU
Ethernet
Total Ethernet
1
10/100/1000 Mbit/s
1
Interfaces
COM Total
7
RS-232
5
RS-485
2
USB Total
2
USB v3.x
2
Digital Input-Output
Channels of DIO
5
Industrial Interfaces
CAN Port
1
Audio
Audio Controller
Intel HD Audio
Drive interfaces
mSATA
1
Storage Cage
Number Of Cage External
1
2.5" Cage Intenal
1
Extension Slots
Total
2
Mini-PCIe/Mini Card
2
SIM Card slots
1
Antenna characteristics
Cellular interfaces
3G
Additional Functions
GPS
GPS
Connectors
Connectors
DB15 VGA, HDMI, RJ45 Ethernet, 2xUSB, Mic In, Line Out, SIM Card Slot, DC input (terminal block), DB15 (COM+GPIO), DB15 Female, 6-pin 12V DC Out
System Power Input
Input Voltage DC
9..36 V
Power Consumption
20 W
Software
Operating System Compatibility
Linux OS, Windows 10
Dimensions and weight
Width
185 mm
Height
45 mm
Depth
120 mm
Operating Conditions
Operating Temperature
-40..70 °C
Vibration
2g @5~500 Hz
Shock
20g
Standards and Certifications
Certifications
CE, FCC Class B
MIL-STD-810
MIL-STD-810F Test Method 516.5 Crash Hazard, MIL-STD-810F Test Method 514.5 Highway Truck
Automotive
e13 Mark
Dimensions
Net Weight
1.1 kg
Gross Weight
1.6 kg
Construction
Construction Chassis
Aluminium Chassis
Mounting Configuration
Embedded, Desktop, Wall
Type
Fanless
CPU
Processor Installed
Intel Atom x5-E3930
Max CPU frequency
1.8 GHz
Memory
Form-factor
DDR3L
Socket Type
1xSODIMM
Default on Board Memory
4 GB
Maximum Memory
8 GB
Assembly
Removable
Graphic
Graphic Controller
Integrated in CPU
Ethernet
Total Ethernet
1
10/100/1000 Mbit/s
1
Interfaces
COM Total
7
RS-232
5
RS-485
2
USB Total
2
USB v3.x
2
Digital Input-Output
Channels of DIO
5
Industrial Interfaces
CAN Port
1
Audio
Audio Controller
Intel HD Audio
Drive interfaces
mSATA
1
Storage Cage
Number Of Cage External
1
2.5" Cage Intenal
1
Extension Slots
Total
2
Mini-PCIe/Mini Card
2
SIM Card slots
1
Antenna characteristics
Cellular interfaces
3G
Additional Functions
GPS
GPS
Connectors
Connectors
DB15 VGA, HDMI, RJ45 Ethernet, 2xUSB, Mic In, Line Out, SIM Card Slot, DC input (terminal block), DB15 (COM+GPIO), DB15 Female, 6-pin 12V DC Out
System Power Input
Input Voltage DC
9..36 V
Power Consumption
20 W
Software
Operating System Compatibility
Linux OS, Windows 10
Dimensions and weight
Width
185 mm
Height
45 mm
Depth
120 mm
Operating Conditions
Operating Temperature
-40..70 °C
Vibration
2g @5~500 Hz
Shock
20g
Standards and Certifications
Certifications
CE, FCC Class B
MIL-STD-810
MIL-STD-810F Test Method 516.5 Crash Hazard, MIL-STD-810F Test Method 514.5 Highway Truck
Automotive
e13 Mark
Dimensions
Net Weight
1.1 kg
Gross Weight
1.6 kg
Construction
Construction Chassis
Aluminium Chassis
Mounting Configuration
Embedded, Desktop, Wall
Type
Fanless
CPU
Processor Installed
Intel Atom x5-E3930
Max CPU frequency
1.8 GHz
Memory
Form-factor
DDR3L
Socket Type
1xSODIMM
Default on Board Memory
4 GB
Maximum Memory
8 GB
Assembly
Removable
Graphic
Graphic Controller
Integrated in CPU
Ethernet
Total Ethernet
1
10/100/1000 Mbit/s
1
Interfaces
COM Total
7
RS-232
5
RS-485
2
USB Total
2
USB v3.x
2
Digital Input-Output
Channels of DIO
5
Industrial Interfaces
CAN Port
1
Audio
Audio Controller
Intel HD Audio
Drive interfaces
mSATA
1
Storage Cage
Number Of Cage External
1
2.5" Cage Intenal
1
Extension Slots
Total
2
Mini-PCIe/Mini Card
2
SIM Card slots
1
Antenna characteristics
Cellular interfaces
3G
Additional Functions
GPS
GPS
Connectors
Connectors
DB15 VGA, HDMI, RJ45 Ethernet, 2xUSB, Mic In, Line Out, SIM Card Slot, DC input (terminal block), DB15 (COM+GPIO), DB15 Female, 6-pin 12V DC Out
System Power Input
Input Voltage DC
9..36 V
Power Consumption
20 W
Software
Operating System Compatibility
Linux OS, Windows 10
Dimensions and weight
Width
185 mm
Height
45 mm
Depth
120 mm
Operating Conditions
Operating Temperature
-40..70 °C
Vibration
2g @5~500 Hz
Shock
20g
Standards and Certifications
Certifications
CE, FCC Class B
MIL-STD-810
MIL-STD-810F Test Method 516.5 Crash Hazard, MIL-STD-810F Test Method 514.5 Highway Truck
Automotive
e13 Mark
Dimensions
Net Weight
1.1 kg
Gross Weight
1.6 kg
Construction
Construction Chassis
Aluminium Chassis
Mounting Configuration
Embedded, Desktop, Wall
Type
Fanless
CPU
Processor Installed
Intel Atom x5-E3930
Max CPU frequency
1.8 GHz
Memory
Form-factor
DDR3L
Socket Type
1xSODIMM
Default on Board Memory
4 GB
Maximum Memory
8 GB
Assembly
Removable
Graphic
Graphic Controller
Integrated in CPU
Ethernet
Total Ethernet
1
10/100/1000 Mbit/s
1
Interfaces
COM Total
7
RS-232
5
RS-485
2
USB Total
2
USB v3.x
2
Digital Input-Output
Channels of DIO
5
Industrial Interfaces
CAN Port
1
Audio
Audio Controller
Intel HD Audio
Drive interfaces
mSATA
1
Storage Cage
Number Of Cage External
1
2.5" Cage Intenal
1
Extension Slots
Total
2
Mini-PCIe/Mini Card
2
SIM Card slots
1
Antenna characteristics
Cellular interfaces
3G
Additional Functions
GPS
GPS
Connectors
Connectors
DB15 VGA, HDMI, RJ45 Ethernet, 2xUSB, Mic In, Line Out, SIM Card Slot, DC input (terminal block), DB15 (COM+GPIO), DB15 Female, 6-pin 12V DC Out
System Power Input
Input Voltage DC
9..36 V
Power Consumption
20 W
Software
Operating System Compatibility
Linux OS, Windows 10
Dimensions and weight
Width
185 mm
Height
45 mm
Depth
120 mm
Operating Conditions
Operating Temperature
-40..70 °C
Vibration
2g @5~500 Hz
Shock
20g
Standards and Certifications
Certifications
CE, FCC Class B
MIL-STD-810
MIL-STD-810F Test Method 516.5 Crash Hazard, MIL-STD-810F Test Method 514.5 Highway Truck
Automotive
e13 Mark
Dimensions
Net Weight
1.1 kg
Gross Weight
1.6 kg
Documentation
VTC-1020-Datasheet-032025.pdf
Documentation
VTC-1020-Datasheet-032025.pdf
Documentation
VTC-1020-Datasheet-032025.pdf
Documentation
VTC-1020-Datasheet-032025.pdf
